3TR7, Hydraulic Hose, 1 Textile Braid, 1 (-16) " I.D., 50' Length, 1,000 PSI, SAE 100R7
(Pack of
50)
SKU:1677592 Item#: 1677592
• Agency Rating: 100R7
• Fittings Certified: 4TA Series, 1A/Z series with sleeve and 901/902 series
• Construction:
– Inner Tube: Nylon
– Reinforcement: One textile braid
– Cover: Polyurethane
• Temperature Range:
– Oil-based fluids: –40°F to +212°F (–40°C to +100°C)
– Water-based fluids: –40°F to +150°F (–40°C to +66°C)
• Application Notes: Recommended for agriculture, horticulture, chemical transfer, foam systems, food processing, forestry delimber, general construction, general hydraulic systems , lubrication systems, marine steering, utility vehicles and pickers, rescue apparatus/tools and water jetter/sewer
Frequently Bought Together
3TR8 Hydraulic Thermoplastic Hose 0.59" x 250'
Couldn't load pickup availability
3TR8 Hydraulic Thermoplastic Hose 0.59" x 50'
Couldn't load pickup availability
3TR18CT Hydraulic Thermoplastic Hose 1.06" x 250'
Couldn't load pickup availability
SAE R2S Hydraulic Hose Rubber 0.75" x 250'
Couldn't load pickup availability
M2T Hydraulic Hose Rubber 0.69" x 50'
Couldn't load pickup availability
MXT Hydraulic Hose Rubber 0.68" x 50'
Couldn't load pickup availability
Z Series Crimp-On Hose End 3/4" x 1-1/16-12
Couldn't load pickup availability
Z Series Crimp-On Hose End 1/4" x 9/16-18
Couldn't load pickup availability
Z Series Crimp-On Hose End 1/2" x 7/8-14
Couldn't load pickup availability
DOT Union Brass 1/2 x 1/2"
Couldn't load pickup availability
Hose Clamp 304 SS 9/16 to 1-1/16"
Couldn't load pickup availability
Silicone Heater/Coolant Hose Clamp 9/16 to 1-1/16"
Couldn't load pickup availability
180-degree Wide Beam Head Light with Side Light
Couldn't load pickup availability
USS Flat Washer Thru-Hardened Steel 5/16"
Couldn't load pickup availability
Stepdown Butt Connector 22 to 18/16 to 14 AWG
Couldn't load pickup availability
3TR18CT Hydraulic Thermoplastic Hose 0.48" x 50'
Couldn't load pickup availability
3TR8 Hydraulic Thermoplastic Hose 0.90" x 50'
Couldn't load pickup availability
3TR7 Hydraulic Thermoplastic Hose 0.82" x 50'
Couldn't load pickup availability
Product Description
• Agency Rating: 100R7• Fittings Certified: 4TA Series, 1A/Z series with sleeve and 901/902 series
• Construction:
– Inner Tube: Nylon
– Reinforcement: One textile braid
– Cover: Polyurethane
• Temperature Range:
– Oil-based fluids: –40°F to +212°F (–40°C to +100°C)
– Water-based fluids: –40°F to +150°F (–40°C to +66°C)
• Application Notes: Recommended for agriculture, horticulture, chemical transfer, foam systems, food processing, forestry delimber, general construction, general hydraulic systems , lubrication systems, marine steering, utility vehicles and pickers, rescue apparatus/tools and water jetter/sewer
Technical Specifications
| Item#: | 1677592 |
|---|---|
| Manufacturer Model #: | 3TR7-16-050BX |
| Type | Thermoplastic Hose |
| Category / Performance | Constant Pressure |
| Industry Rating 1 | SAE 100R7 |
| Manufacturer Series Number | 3TR7 |
| Manufacturer Series Name | Synflex |
| Dash Size | -16 |
| Working Pressure | 1,000 PSI |
| Burst Pressure | 4,000 PSI |
| Inner Tube Material | Nylon |
| Hose Reinforcement | 1 Textile Braid |
| Hose Cover Material | Non-Stick Polyurethane 3TR7 Perforated |
| Fitting Series | 4TA Series, 1A/Z Series with Sleeve and 901/902 Series |
| Temperature | Oil Basedluids = -40F to +212F / Water Basedluids = -40F to +150 F |
| Color | Black |
| Size | 1 (-16) " |
| Length | 50 ft |
| SynFlex Part No. | 3TR7-16-050BX |
| UNSPSC #: | 40142020 |
| TAA Compliant: | Yes |
