Battery Cable 3/0 AWG Black Purple-Crimp Code
(Pack of
1.0)
• Stranded copper conductors are soft annealed for improved flexibility
• Tough polyvinyl chloride insulator resists abrasion, oil, grease and moisture, and is flame-retardant
• Color-coded layline indicates wire gauge
• Meets SAE Specification J1127 for automobiles, buses and trucks
• Temperature range: –40°F to +140°F (–40°C to +60°C)
• 50V maximum
Frequently Bought Together
Flexible Battery Cable 8 AWG Red 25'
Item#: P52436
Couldn't load pickup availability
Flexible Battery Cable 3/0 AWG Red 25'
Item#: P52742
Couldn't load pickup availability
Battery Cable 1 AWG 50' Pink
Item#: 98409
Couldn't load pickup availability
Cable Tie 7.31" Black
Item#: 85487
Couldn't load pickup availability
ATO/ATC Fuse 15A Blue
Item#: 84789
Couldn't load pickup availability
Cable Tie 14.19" Black
Item#: 85489
Couldn't load pickup availability
Straight Barrel Battery Terminal 2/0 AWG Positive
Item#: 41413
Couldn't load pickup availability
DT Series Plug 13A 4 Contacts
Item#: 29494
Couldn't load pickup availability
DT Series Receptacle 13A 4 Contacts
Item#: 29493
Couldn't load pickup availability
Superbutt Connector 22 to 18 AWG Red
Item#: 94727
Couldn't load pickup availability
Superbutt Connector 16 to 14 AWG Blue
Item#: 94728
Couldn't load pickup availability
Flat Washer Grade 12 Thru-Hardened Steel M8
Item#: 87510
Couldn't load pickup availability
Product Description
• Stranded copper conductors are soft annealed for improved flexibility• Tough polyvinyl chloride insulator resists abrasion, oil, grease and moisture, and is flame-retardant
• Color-coded layline indicates wire gauge
• Meets SAE Specification J1127 for automobiles, buses and trucks
• Temperature range: –40°F to +140°F (–40°C to +60°C)
• 50V maximum
Technical Specifications
| Item#: | 84801 |
|---|---|
| Cable Gauge | 3/0 |
| Color | Black |
| Volts | 50 V |
| Minimum Temperature Rating | -40 °F |
| Maximum Temperature Rating | 140 °F |
| Length | 25 ft |
| Crimp Color Code | Purple |
| Specifications | SAE J1127 |
| Style | Tru-Conduct |
| Type | Battery Cable |
| O.D. | 3/4 " |
| UNSPSC #: | 39121405 |
| TAA Compliant: | Yes |
| Weight: | 16.65 lb |
