Battery Cable, 3/0 AWG, 25' Length, Black, 50 Volts, PVC Insulated, Purple-Crimp Color Code, Copper Conductor, Tru-Conduct
(Pack of
1)
• Stranded copper conductors are soft annealed for improved flexibility
• Tough polyvinyl chloride insulator resists abrasion, oil, grease and moisture, and is flame-retardant
• Color-coded layline indicates wire gauge
• Meets SAE Specification J1127 for automobiles, buses and trucks
• Temperature range: –40°F to +140°F (–40°C to +60°C)
• 50V maximum
Frequently Bought Together
Flexible Battery Cable 6 AWG Black 50'
Item#: P52457
Couldn't load pickup availability
Cable Seal Green 20-18 AWG 20A 12V
Item#: 96904
Couldn't load pickup availability
2-Way Inline Connection Kit 16-14 AWG
Item#: 1446722
Couldn't load pickup availability
Hex Nut Grade 8 Alloy Steel 5/16-18
Item#: A101
Couldn't load pickup availability
Product Description
• Stranded copper conductors are soft annealed for improved flexibility• Tough polyvinyl chloride insulator resists abrasion, oil, grease and moisture, and is flame-retardant
• Color-coded layline indicates wire gauge
• Meets SAE Specification J1127 for automobiles, buses and trucks
• Temperature range: –40°F to +140°F (–40°C to +60°C)
• 50V maximum
Technical Specifications
| Item#: | 84801 |
|---|---|
| Cable Gauge | 3/0 |
| Color | Black |
| Volts | 50 V |
| Minimum Temperature Rating | -40 °F |
| Maximum Temperature Rating | 140 °F |
| Length | 25 ft |
| Crimp Color Code | Purple |
| Specifications | SAE J1127 |
| Style | Tru-Conduct |
| Type | Battery Cable |
| O.D. | 3/4 " |
| UNSPSC #: | 39121405 |
| TAA Compliant: | Yes |
| Weight: | 16.65 lb |
