Caster Rigid Heavy-Duty 6 x 2" Wheel
(Pack of
1.0)
Mold-On PolyurethaneThis wheel has a polyurethane tread permanently molded and mechanically locked to an aluminum hub. It provides easy rolling, high load capacity, good floor protection and long service life. Sold with a roller bearing. Tread hardness: 55 Shore D.
• Finish is yellow zinc chromate – twice as corrosion-resistant as clear zinc
• Roller wheel bearings
• Upper raceway grease seal retains lubricant and excludes contaminants
• Grease zerk fitting in upper raceway and axle for easy maintenance
• 1/2" dia. nut and bolt grease fitting axle
• Mold-on polyurethane wheels are molded to an aluminum hub
Top Plate Dimensions
Overall Size: 4" x 4-1/2"
Hole Spacing: 2-5/8" x 3-5/8" to 3" x 3"
Hole Size: 3/8" x 3/4" slots
Bolt Dia.: 3/8"
• Applications include trucks and hoppers, carts and racks, dollies and other mobile equipment
Frequently Bought Together
Caster Swivel Heavy-Duty 5 x 2" Wheel
Couldn't load pickup availability
Brake Kit For Institutional Casters 5" Wheel
Couldn't load pickup availability
Caster Rigid Heavy-Duty 6 x 2" Wheel
Couldn't load pickup availability
36" Blue Stretch Master Nylon Slotted Strap
Couldn't load pickup availability
Tarp Strap Epdm Rubber with Hooks 28" Long
Couldn't load pickup availability
Tuff-Edge® Web Sling, Polyester, Silver, 6' Length
Couldn't load pickup availability
Caster Rigid Heavy-Duty 6 x 2" Wheel
Couldn't load pickup availability
Caster Swivel with Brake Polyurethane Wheel
Couldn't load pickup availability
Caster Swivel Lite-Med Duty 3-1/2 x 1-1/4" Wheel
Couldn't load pickup availability
USS Flat Washer Thru-Hardened Steel 5/16"
Couldn't load pickup availability
SAE Flat Washer Thru-Hardened Steel 5/16"
Couldn't load pickup availability
SAE J995C Locknut with Nylon Insert Grade 8 3/8-16
Couldn't load pickup availability
Product Description
Mold-On PolyurethaneThis wheel has a polyurethane tread permanently molded and mechanically locked to an aluminum hub. It provides easy rolling, high load capacity, good floor protection and long service life. Sold with a roller bearing. Tread hardness: 55 Shore D.• Finish is yellow zinc chromate – twice as corrosion-resistant as clear zinc
• Roller wheel bearings
• Upper raceway grease seal retains lubricant and excludes contaminants
• Grease zerk fitting in upper raceway and axle for easy maintenance
• 1/2" dia. nut and bolt grease fitting axle
• Mold-on polyurethane wheels are molded to an aluminum hub
Top Plate Dimensions
Overall Size: 4" x 4-1/2"
Hole Spacing: 2-5/8" x 3-5/8" to 3" x 3"
Hole Size: 3/8" x 3/4" slots
Bolt Dia.: 3/8"
• Applications include trucks and hoppers, carts and racks, dollies and other mobile equipment
Technical Specifications
| Item#: | 10847 |
|---|---|
| Type | Rigid |
| Style | Heavy Duty |
| Wheel Type | Mold-on Polyurethane |
| Wheel Diameter | 6 " |
| Wheel Width | 2 " |
| Load Rating | 1,200 lb |
| Top Plate Overall Size | 4 x 4-1/2 " |
| Top Plate Bolt Diameter | 3/8 " |
| Top Plate Hole Spacing | 2-5/8 x 3-5/8 to 3 x 3 " |
| Top Plate Hole Diameter | 3/8 x 3/4 slots " |
| Finish | Yellow Zinc Chromate |
| UNSPSC #: | 31162701 |
| TAA Compliant: | Yes |
| Weight: | 5.9 lb |
