Closed End Connector, 12 to 10 AWG, Nylon Insulated, Clear, -40 to 221°F Temperature Rating
(Pack of
100)
• Color-coded for easy wire size identification
• Visible crimp zone lets you make a visible, safe crimp
• Can be used on solid or stranded wire or any combination of the two
• Easily removed, no need to cut wires, simply recrimp 90° to original crimp
• Three sizes cover all your wiring needs from 22 AWG through 10 AWG
• Pure electrolytic copper promotes high conductivity
• Can be crimped anywhere on the barrel
• Rated 600V maximum at 221°F (105°C)• Temperature range: –40°F to +221°F (–40°C to +105°C)
Frequently Bought Together
Closed End Connector 600V 22 to 14 AWG Yellow
Item#: 1145759
Couldn't load pickup availability
Closed End Connector 600V 22 to 12 AWG Red
Item#: 1145800
Couldn't load pickup availability
Closed End Connector 600V 16 to 10 AWG Blue
Item#: 1145894
Couldn't load pickup availability
Tru-Shrink Heat Shrink Tubing 14 to 6 AWG Black
Item#: 86502
Couldn't load pickup availability
SAE Flat Washer Thru-Hardened Steel 5/8"
Item#: FA88441
Couldn't load pickup availability
Male Quick Slide Terminal 16 to 14 AWG Blue
Item#: 25287
Couldn't load pickup availability
Product Description
• Color-coded for easy wire size identification• Visible crimp zone lets you make a visible, safe crimp
• Can be used on solid or stranded wire or any combination of the two
• Easily removed, no need to cut wires, simply recrimp 90° to original crimp
• Three sizes cover all your wiring needs from 22 AWG through 10 AWG
• Pure electrolytic copper promotes high conductivity
• Can be crimped anywhere on the barrel
• Rated 600V maximum at 221°F (105°C)• Temperature range: –40°F to +221°F (–40°C to +105°C)
Technical Specifications
| Item#: | P37157 |
|---|---|
| Type | Electrical Connectors |
| Wire Gauge | 12-10 AWG |
| Color | Clear |
| Voltage Rating | 600 V maximum at 221 degrees F |
| Temperature Rating | -40 to 221 F |
| Style | Visa Crimp Closed End Connectors |
| UNSPSC #: | 39121409 |
| TAA Compliant: | No |
| Weight: | 0.61 lb |
