Home Facility + Site Compression Spring 1/4 x 1-1/2"
Facility + Site

Compression Spring 1/4 x 1-1/2"
(Pack of 10.0)

Lawson Products

• The most common spring type
• Used in applications where mechanical parts must be separated by constant applied force
To determine the spring rate for a length not shown, divide the original length by the desired length, then multiply by the original spring rate.Example: The rate for No. 89581, cut to 1", would be 3 divided by 1, then multiplied by 2.0, or 6 lbs. per inch.

Read More
Check Availability

Catalog page#: 16-36

Frequently Bought Together


Universal High-Visibility Sorbent Pad

Item#: 1566093

Automotive Refinishing Tape 2" x 60 Yards

Item#: 50117

WypAll X80 ShopPro Towel 12.5 x 13.4"

Item#: 29372

WypAll X80 ShopPro Towel 12.5 x 16.8"

Item#: 29371

Split Key Ring 1"

Item#: 95873

Valve Action® Permanent Paint Marker Yellow

Item#: 99062

Butt Connector 22 to 18 AWG Clear

Item#: 1368140

Butt Connector 16 to 14 AWG Blue

Item#: 92823

USS Flat Washer Thru-Hardened Steel 3/8"

Item#: 88447

WypAll X80 ShopPro Towel 9.1 x 16.8"

Item#: 28137

General Purpose Duct Tape 2" x 60 Yards

Item#: 58000

Valve Action® Permanent Paint Marker Black

Item#: 1351780

Extension Spring 13/32 x 4-1/2"

Item#: 89702

Extension Spring 1-1/16 x 7"

Item#: 89665

Extension Spring 7/8 x 6"

Item#: 89662

Product Description

• The most common spring type
• Used in applications where mechanical parts must be separated by constant applied force
To determine the spring rate for a length not shown, divide the original length by the desired length, then multiply by the original spring rate.Example: The rate for No. 89581, cut to 1", would be 3 divided by 1, then multiplied by 2.0, or 6 lbs. per inch.

Technical Specifications

Item#: 89568
Type Compression Spring
O.D. 11/32 "
Length 1-1/2 "
I.D. 1/4 "
Wire Diameter 0.048 "
Wire Gauge 18
Number of Coils 14
Rate 23 lb./in.
Maximum Work Load 16 lb
Material Steel
UNSPSC #: 31161904
TAA Compliant: Yes
Weight: 0.09 lb
