Connecting Link, Single Strand, Steel, Industry No. 50, 5/8
Connecting Link, Single Strand, Steel, Industry No. 50, 5/8

Connecting Link, Single Strand, Steel, Industry No. 50, 5/8" Pitch, 6,930lbs Average Tensile Strength
(Pack of 5)

Item#: 85372

Daido®

Connecting Link, Single Strand, Steel, Industry No. 50, 5/8" Pitch, 6,930lbs Average Tensile Strength

Read More
Check Availability

Catalog page#: 15-59

Frequently Bought Together

Offset Link (Half Link), Single Strand, Steel, Nickel Plated, Industry No. 35, 3/8

Offset Link (Half Link), Single Strand, Steel, Nickel Plated, Industry

Item#: 1443532
Connecting Link, Double Pitch-Conveyor, Stainless Steel, Industry No. C2052, 1-1/4

Connecting Link, Double Pitch-Conveyor, Stainless Steel, Industry No.

Item#: 1443466
Offset Link (Half Link), Double Strand, Steel, Industry No. 12B-2, 3/4

Offset Link (Half Link), Double Strand, Steel, Industry No. 12B-2

Item#: 1443438
Screw Pin Anchor Shackle, 3/8

Screw Pin Anchor Shackle, 5/16", 2,000 lb WLL

Item#: 1429879
Tarp Strap Epdm Rubber with Hooks 28

Tarp Strap Epdm Rubber with Hooks 35" Long

Item#: 99564
Screw Pin Anchor Shackle, 5/8

Screw Pin Anchor Shackle, 5/8", 6,500 lb WLL

Item#: 1424883
Offset Link (Half Link), Single Strand, Heavy, Steel, Industry No. 100H, 1-1/4

Offset Link (Half Link), Single Strand, Heavy, Steel, Industry No. 60H

Item#: 85388
Roller Chain, Single Strand, Steel, Nickel Plated, Industry No. 25, 1/4

Roller Chain, Single Strand, Steel, Nickel Plated, Industry No. 41

Item#: 1443389
Roller Chain, Single Strand, Stainless Steel, Industry No. 35, 3/8

Roller Chain, Single Strand, Stainless Steel, Industry No. 40

Item#: 1443418
SAE Flat Washer Thru-Hardened Steel 5/16

SAE Flat Washer Thru-Hardened Steel 5/16"

Item#: 88436
Self-Drilling Screw Hex Head #6-20 x 1/2

Self-Drilling Screw Hex Head 1/4-14 x 1"

Item#: 2539
USS Flat Washer Thru-Hardened Steel 5/16

USS Flat Washer Thru-Hardened Steel 5/16"

Item#: FA88446

Product Description

Connecting Link, Single Strand, Steel, Industry No. 50, 5/8" Pitch, 6,930lbs Average Tensile Strength

Technical Specifications

Item#: 85372
Manufacturer Model #: CL50
Configuration Connecting Link
Type Single Strand
Style Standard
Material Steel
Finish Plain
Industry Number 50
Pitch 5/8 "
Roller Width 0.375 "
Roller Diameter 0.400 "
Plate Thickness 0.079 "
Plate Height 0.591 "
Minimum Tensile Strength 5,940 lb
Average Tensile Strength 6,930 lb
Maximum Load 1,540 lb
UNSPSC #: 31163027
TAA Compliant: Yes
Weight: 0.2 lb
