DT Series Plug, 13 Amps, 12 Contacts, Contact Size 16
(Pack of
1)
SKU:29499 Item#: 29499
Ensure seamless and secure connections, even in the toughest conditions, with the DT Series Plug. Designed to excel in cable-to-cable, cable-to-board, and cable-to-device applications, this environmentally-sealed connector offers reliability and durability that automotive and industrial professionals can count on. With a current rating of 13 Amps, a wide temperature range from -67°F to +257°F, and a dielectric strength of 1,500V, the DT Series Plug is engineered to perform under extreme circumstances. Whether you're tackling demanding automotive repairs or industrial installations, this connector simplifies the job while ensuring the safety and longevity of your work.
• Contact size: 16
• Current rating: 13 Amps
• Temperature range: –67°F to +257°F (–55°C to +125°C)
• Dielectric strength: 1,500V minimum
• DT Series (Deutsch); AT Series (Amphenol)
Couldn't load pickup availability
Frequently Bought Together
Female Quick Slide Terminal 16 to 14 AWG Blue
Couldn't load pickup availability
Female Quick Slide Terminal 16 to 14 AWG Clear
Couldn't load pickup availability
MINI Fuse 10A Red
Couldn't load pickup availability
Battery Terminal 4-2/0 AWG 5/16" Stud Negative
Couldn't load pickup availability
Battery Terminal Nut Universal 16 TPI
Couldn't load pickup availability
Heavy-Duty Battery Cable Lug 1/0 AWG Pink 5/16"
Couldn't load pickup availability
Locknut with Nylon Insert Grade 8 5/16-18
Couldn't load pickup availability
Superbutt Connector 22 to 18 AWG Red
Couldn't load pickup availability
Nutsetter & Bit Set, Magnetic, 22pc
Couldn't load pickup availability
DT Series Plug 13A 6 Contacts
Couldn't load pickup availability
Socket Contact 14-12 AWG Size 12
Couldn't load pickup availability
DT Series Receptacle 13A 8 Contacts
Couldn't load pickup availability
Product Description
Ensure seamless and secure connections, even in the toughest conditions, with the DT Series Plug. Designed to excel in cable-to-cable, cable-to-board, and cable-to-device applications, this environmentally-sealed connector offers reliability and durability that automotive and industrial professionals can count on. With a current rating of 13 Amps, a wide temperature range from -67°F to +257°F, and a dielectric strength of 1,500V, the DT Series Plug is engineered to perform under extreme circumstances. Whether you're tackling demanding automotive repairs or industrial installations, this connector simplifies the job while ensuring the safety and longevity of your work.• Contact size: 16
• Current rating: 13 Amps
• Temperature range: –67°F to +257°F (–55°C to +125°C)
• Dielectric strength: 1,500V minimum
• DT Series (Deutsch); AT Series (Amphenol)
Technical Specifications
| Item#: | 29499 |
|---|---|
| Style | DT Series |
| Connection Type | Plug |
| Number of Contacts | 12 |
| UNSPSC #: | 39121432 |
| TAA Compliant: | No |
| Weight: | 0.03 lb |
