Home Hydraulics Hose and Tubing Accessories Reels EZ-Coil Air/Water Hose Reel /2" x 75'
Accessories
Super HubT Air/Water Hose Reel 1/2
Super HubT Air/Water Hose Reel 1/2

EZ-Coil Truck-Mount Air Hose Reel, Double Axle Support to Center Shaft, 300PSI, 82lbs, 1/2" x 75'
(Pack of 1)

Item#: 20782

Coxreels®

EZ-Coil® Patented Safety Recoil Mechanism
• Retracts hose at rates up to 80% slower than conventional reels
• Significantly reduces potential for hose whip injuries and damage
Super Hub™ Axle Support System Features
• Double axle support to center shaft
• 1" solid steel axle with lubricated precision bearings
• Increased stability during operation for reduced vibration and higher reel strength
Truck-Mounted Reels
• Super Hub™-equipped with triple axle support to center shaft
• 1" solid steel axle with lubricated precision bearings
• Increased stability during operation for reduced vibration and higher reel strength
Standard Features
• Compact design
• Heavy gauge 1/4" steel base and support post
• Factory matched cartridge style spring motor
• Brass NPT swivel inlet machined from solid brass
• Nitrile swivel seals
• 1" solid steel axle with lubricated precision bearings
• High-quality air hose provided (unless otherwise specified)

Read More
Check Availability

Catalog page#: 8-145

Frequently Bought Together

Blushield Steel Pressure Washer Manual Hose Reel 100' Length

Blushield Steel Pressure Washer Manual Hose Reel 100'

Item#: 1690623
OilShield Dual-Arm Air Hose Reel All-In-One 1/2

OilShield Dual-Arm Air Hose Reel All-In-One 1/2" x 50'

Item#: 1690614
BluShield Steel A Frame 150' Pressure Washer Hose Reel, BluShield Steel A Frame 150' Length Pressure Washer Hose Reel

BluShield Steel A Frame 150' Pressure Washer Hose Reel

Item#: 1690625
Polyurethane Self-Coiling Air Hose Assembly 1/4

Polyurethane Self-Coiling Air Hose Assembly 1/4" NPT x 0.160" ID x 10' Length

Item#: 52134
FLEXAIR 1/4

FLEXAIR 1/2" I.D. x 50' air hose assembly w/ High Flow safety coupler

Item#: 1637171
Jackhammer Air Hose Assembly 3/4

Jackhammer Air Hose Assembly 3/4" x 50' Red

Item#: 41461
Pipe Street Elbow Brass 90° 1/8-27 x 1/8-27, Pipe Street Elbow, Brass, 90°, 1/8-27 x 1/8-27, Male NPT x Female NPT, 1200PSI

Pipe Street Elbow Brass 90° 3/8-18 x 3/8-18

Item#: 5317
DOT Connector Male Brass 3/8 x 3/8-18, DOT Air Brake Push to Connect Connector, Male, Brass, 3/8 x 3/8-18, Tube x Pipe

DOT Connector Male Brass 1/4 x 1/4-18

Item#: 57505
DOT Swivel Elbow Male 90° Brass 3/8 x 1/2-14, DOT Air Brake Push to Connect Swivel Elbow, 90°, Male, Brass, 3/8 x 1/2-14

DOT Swivel Elbow Male 360° Brass 3/8 x 1/4-18

Item#: 27205
Single Wire Pressure Washing Hose 3/8

Single Wire Pressure Washing Hose 3/8 " ID, 100'

Item#: 1694092
Rotary Switch for Humpback Pump, Blue, Plastic

Rotary Switch for Humpback Pump

Item#: 1694082
Humpback Reel Accessories - PW Lance, Humpback Pressure Washing Lance, Steel

Humpback Reel Accessories - PW Lance

Item#: 1694080
Blushield Steel Pressure Washer Manual Hose Reel 100' Length

Blushield Steel Pressure Washer Manual Hose Reel 100'

Item#: 1690623
OilShield Dual-Arm Air Hose Reel All-In-One 1/2

OilShield Dual-Arm Air Hose Reel All-In-One 1/2" x 50'

Item#: 1690614
BluShield Steel A Frame 150' Pressure Washer Hose Reel, BluShield Steel A Frame 150' Length Pressure Washer Hose Reel

BluShield Steel A Frame 150' Pressure Washer Hose Reel

Item#: 1690625
IFI 100/107 Top Locknut Grade C 1-8, IFI 100/107 Top Locknut, Grade C, Alloy Steel, Zinc/Wax Finish, Coarse Thread

IFI 100/107 Top Locknut Grade C 5/8-11

Item#: 80933
Locknut with Nylon Insert Grade 8 5/16-24, Locknut with Nylon Insert, Grade 8, Alloy Steel, Yellow Zinc Finish, Fine Thread

Locknut with Nylon Insert Grade 8 5/16-18

Item#: 53980
Vision Pro Super Illuminator Work Light

Vision Pro Super

Item#: DY21061040

Product Description

EZ-Coil® Patented Safety Recoil Mechanism
• Retracts hose at rates up to 80% slower than conventional reels
• Significantly reduces potential for hose whip injuries and damage
Super Hub™ Axle Support System Features
• Double axle support to center shaft
• 1" solid steel axle with lubricated precision bearings
• Increased stability during operation for reduced vibration and higher reel strength
Truck-Mounted Reels
• Super Hub™-equipped with triple axle support to center shaft
• 1" solid steel axle with lubricated precision bearings
• Increased stability during operation for reduced vibration and higher reel strength
Standard Features
• Compact design
• Heavy gauge 1/4" steel base and support post
• Factory matched cartridge style spring motor
• Brass NPT swivel inlet machined from solid brass
• Nitrile swivel seals
• 1" solid steel axle with lubricated precision bearings
• High-quality air hose provided (unless otherwise specified)

Technical Specifications

Item#: 20782
Manufacturer Model #: EZ-TSH-475
Type Hose Reels - Air/Water
Description EZ-Coil® Truck-Mount Air Hose Reel
Category / Performance Best
Size 1/2X75
Length 75 ft
I.D. 1/2 "
Working Pressure 300 PSI
Cox Part Number EZ-TSH-475
Weight 82 lb
Quantity Per Package 1.0000
UNSPSC #: 40142022
TAA Compliant: Yes
Weight: 82.0 lb
