Home Hydraulics Fittings Brass Forged Body Ball Valve Brass 2 x 2"
Brass
Forged Body Ball Valve Brass 2 x 2
Forged Body Ball Valve Brass 2 x 2

Forged Body Ball Valve, Brass, 2 x 2", Female NPT x Female NPT, 600PSI
(Pack of 1)

Item#: 63141

Lawson Products

For use in gas and pneumatic lines, this Forged Body Ball Valve is ideal for high-pressure and high-temperature applications where reliability and safety are important. Made of brass with dual sealing system that allows valve to be operated in either direction making installation easier. Other advantages include no metal-to-metal moving parts, a handle clearly showing ball position and no maintenance requirements.
• 24-hour 100% seal test guaranteed
• Working pressure: 600 PSI
• Operating temperature: –40°F to +350°F
• Chrome plated brass ball for longer life
• Silicone-free lubricant on all seals
• Approvals: CSA, FM, UL, CUL, Federal Specification WW-V-35C
Applications:
• Gas
• Pneumatic lines
• Travel stops on body to avoid stresses at stem
• Hot forged, sand blasted, unplated brass body and cap sealed with Loctite® or equivalent thread sealant
• Finest brass according to EN 12165 and EN 12164 specifications
• Full port to DIN 3357 for maximum flow
• NPT taper ANSI B.1.20.1 female by female threads
• Blowout-proof nickel plated brass stem
• Two FPM O-rings at the stem for maximum safety
• Geomet® carbon steel handle with thick PVC dip coating for thermal and electrical protection
• Handle removable with valve in service
• Pure PTFE self-lubricating seats with flexible-lip design

Read More
Check Availability

Catalog page#: 9-25

Frequently Bought Together

Pipe Tee Brass 1/4-18 x 1/4-18 x 1/4-18, Pipe Tee, Brass, 1/4-18 x 1/4-18 x 1/4-18, Female NPT x Female NPT x Female NPT

Pipe Tee Brass 1/2-14 x 1/2-14 x 1/2-14

Item#: 86667
Square Head Plug Brass 3/8-18 Male NPT, Square Head Plug, Brass, 3/8-18, Male NPT, 1200PSI

Square Head Plug Brass 1/4-18 Male NPT

Item#: 5273
Reducing Coupling Brass 3/8-18 x 1/4-18, Reducing Coupling, Brass, 3/8-18 x 1/4-18, Female NPT x Female NPT, 1200PSI

Reducing Coupling Brass 3/8-18 x 1/4-18

Item#: 5310
Premium Greasing Accessory 11 Piece Kit with Case , 1/8

Premium Greasing Accessory 11 Piece Kit

Item#: 1677924
DOT Swivel Elbow Male 45° Brass 1/2 x 3/8-18, DOT Air Brake Push to Connect Swivel Elbow, 45°, Male, Brass, 1/2 x 3/8-18

DOT Swivel Elbow Male 45° Brass 1/4 x 1/4-18

Item#: 28970
DOT Swivel Run Tee Male Brass 1/4 x 1/8-27 x 1/4

DOT Swivel Run Tee Male Brass 1/4 x 1/8-27 x 1/4"

Item#: 28983
DOT Connector Female Brass 3/8 x 1/8-27, DOT Air Brake Push to Connect Connector, Female, Brass, 3/8 x 1/8-27, Tube x Pipe

DOT Connector Female Brass 3/8 x 1/8-27

Item#: 28968
Premium Greasing Accessory 11 Piece Kit with Case , 1/8

Premium Greasing Accessory 11 Piece Kit

Item#: 1677924
DOT Swivel Elbow Male 45° Brass 1/2 x 3/8-18, DOT Air Brake Push to Connect Swivel Elbow, 45°, Male, Brass, 1/2 x 3/8-18

DOT Swivel Elbow Male 45° Brass 1/4 x 1/4-18

Item#: 28970
Push-to-Connect Elbow, Nickel-Plated Brass/PBT Resin, 1/4 x 1/8

Push-to-Connect Elbow, Nickel-Plated Brass/PBT Resin, 1/4 x 1/8"

Item#: 86760
Pipe Street Elbow Brass 45° 3/8-18 x 3/8-18, Pipe Street Elbow, Brass, 45°, 3/8-18 x 3/8

Pipe Street Elbow Brass 45° 1/4-18 x 1/4-18

Item#: 5313
Pipe Adapter Brass 1/4-18 x 3/8-18, Pipe Adapter, Brass, 1/4-18 x 3/8-18, Male NPT x Female NPT, 1200PSI

Pipe Adapter Brass 1/8-27 x 1/4-18

Item#: 5279
Z Series Crimp-On Hose End 1/2

Z Series/1A Series Crimp-On Hose End 1/4" x 9/16-18

Item#: 16610
Silicone Heater/Coolant Hose Clamp SS 2-1/16 to 3

Silicone Heater/Coolant Hose Clamp 13/16 to 1-1/2"

Item#: 88720
Quick Disconnect Coupler Steel 1/4

Quick Disconnect Coupler Steel 1/4" x 1/4-18

Item#: 11914
Autobahn Ergo Magna EZ Crimper Ratcheting Terminal Crimper

Autobahn Ergo Magna EZ Crimper Ratcheting Terminal Crimper

Item#: DY89310247
SAE Flat Washer Thru-Hardened Steel 3/8

SAE Flat Washer Thru-Hardened Steel 3/8"

Item#: FA88437
Hex Nut Grade 5 Steel 5/8-18, ANSI B18.2.2 Hex Nut, Grade 5, Steel, Zinc Finish, Fine Thread, 15/16

Hex Nut Grade 5 Steel 3/8-16

Item#: FA95679
BK1 Bearkat Safety Glasses, Frost Black Frame, Gray Lens, Scratch-Resistant Coating

BK1 Bearkat Safety Glasses

Item#: SF10914
Weatherhead H280 Hydraulic Hose Rubber 0.53

Weatherhead H280 Hydraulic Hose 1.09" x 250'

Item#: 50800 12
AMBI-DEX® GRIPPAZ™ Nitrile Glove with Textured Fish Scale Grip - 7 Mil

AMBI-DEX® GRIPPAZ™ Nitrile Glove with Textured Fish Scale Grip - 7 Mil

Item#: 1655284

Product Description

For use in gas and pneumatic lines, this Forged Body Ball Valve is ideal for high-pressure and high-temperature applications where reliability and safety are important. Made of brass with dual sealing system that allows valve to be operated in either direction making installation easier. Other advantages include no metal-to-metal moving parts, a handle clearly showing ball position and no maintenance requirements.
• 24-hour 100% seal test guaranteed
• Working pressure: 600 PSI
• Operating temperature: –40°F to +350°F
• Chrome plated brass ball for longer life
• Silicone-free lubricant on all seals
• Approvals: CSA, FM, UL, CUL, Federal Specification WW-V-35C
Applications:
• Gas
• Pneumatic lines
• Travel stops on body to avoid stresses at stem
• Hot forged, sand blasted, unplated brass body and cap sealed with Loctite® or equivalent thread sealant
• Finest brass according to EN 12165 and EN 12164 specifications
• Full port to DIN 3357 for maximum flow
• NPT taper ANSI B.1.20.1 female by female threads
• Blowout-proof nickel plated brass stem
• Two FPM O-rings at the stem for maximum safety
• Geomet® carbon steel handle with thick PVC dip coating for thermal and electrical protection
• Handle removable with valve in service
• Pure PTFE self-lubricating seats with flexible-lip design

Technical Specifications

Item#: 63141
Fitting Type Ball Valve
Configuration Forged Body for Gas Lines
Material Brass
Connection Type A x B Female NPT x Female NPT
Fitting Dimension A 2-11-1/2
Fitting Dimension B 2-11-1/2
Working Pressure 600 PSI
Temperature Range -40 to 350 °F
UNSPSC #: 40170000
TAA Compliant: No
Weight: 3.92 lb
