Hex Cap Screw, Grade 8, Alloy Steel, Yellow Zinc Finish, Fine Thread, 25/32" Head Height, 1-7/8" Across Flats, 1-1/4-12 x 4"
(Pack of
1)
• 150,000 PSI minimum tensile strength (SAE Grade 8)
• Conforms to SAE J429 material and mechanical properties
• Available in coarse (UNC) and fine (UNF) thread types
• Product dimensions to ANSI B18.2.1
Frequently Bought Together
Hex Cap Screw Grade 5 3/8-16 x 1-1/4"
Item#: FA65033
Couldn't load pickup availability
Hex Cap Screw Grade 8 Alloy Steel 3/8-16 x 1-1/4"
Item#: 633
Couldn't load pickup availability
Hex Cap Screw 18-8 Stainless Steel 1/4-20 x 3/4"
Item#: 91007
Couldn't load pickup availability
Hex Cap Screw Grade 5 3/8-16 x 1-1/4"
Item#: FA65033
Couldn't load pickup availability
Hex Cap Screw Grade 8 Alloy Steel 3/8-16 x 1-1/4"
Item#: 633
Couldn't load pickup availability
Hex Cap Screw 18-8 Stainless Steel 1/4-20 x 3/4"
Item#: 91007
Couldn't load pickup availability
SAE Flat Washer Thru-Hardened Steel 3/8"
Item#: FA88437
Couldn't load pickup availability
Hex Nut Grade 8 Alloy Steel 5/16-18
Item#: A101
Couldn't load pickup availability
Hex Nut Grade 5 Steel 1/4-20
Item#: FA95677
Couldn't load pickup availability
SAE Flat Washer Thru-Hardened Steel 1/4"
Item#: 88435
Couldn't load pickup availability
Hex Nut Grade 8 Alloy Steel 3/8-16
Item#: A102
Couldn't load pickup availability
Hex Nut Grade 8 Alloy Steel 1/2-13
Item#: A104
Couldn't load pickup availability
Product Description
• 150,000 PSI minimum tensile strength (SAE Grade 8)• Conforms to SAE J429 material and mechanical properties
• Available in coarse (UNC) and fine (UNF) thread types
• Product dimensions to ANSI B18.2.1
Technical Specifications
| Item#: | FA21269A |
|---|---|
| Style | Standard |
| Diameter | 1-1/4 " |
| Thread Pitch | 12 |
| Thread | Fine |
| Length | 4 " |
| Type | Hex Cap Screw |
| Across Flats | 1-7/8 " |
| Material | Alloy Steel |
| Grade | 8 |
| Finish | Yellow Zinc |
| Tensile Strength | 150,000 PSI |
| Specifications | SAE J429 |
| Head Style | Hex |
| Head Height | 25/32 " |
| Thread Form | UNR |
| Thread Length | Partial |
| Thread Length Minimum | 2-3/4 " |
| UNSPSC #: | 31161501 |
| TAA Compliant: | Yes |
| Weight: | 1.9 lb |
