Hospital Grade Duplex Receptacle, 2-Pole, 3-Wire, 15 Amps, 125 Volts, Ivory, NEMA 5-15R
(Pack of
1)
SKU:82551 Item#: 82551
• Green dot signifies Hospital Grade
• 2 pole, 3 wire
• Double-wipe, copper alloy grounding contacts
• One-piece, triple-wipe brass line contacts
• Heavy-duty, copper alloy self-grounding strap
• High-impact, chemical-resistant nylon face and back
• Strip gauge for accurate back wiring
• Heavy-duty, double-plated wraparound steel yoke locked in for maximum strength and security
• Back wiring – eight wiring pockets for convenient feed-through wiring, clamp-type terminals
• Large No. 10 binding head terminal screws fasten wire securely and easily – backed out and staked for fast wiring
• Extra-large green hex head grounding screw for positive grounding
• Break-off tabs for split-circuit wiring
• Thread-cleaning captive mounting screws
• All Lawson Hospital Grade wiring devices conform to OSHA and NEMA specifications and all other safety regulations• Entire device meets or exceeds UL, CSA, NEMA/ANSI and Federal specifications
Couldn't load pickup availability
Catalog page#: 17-88
Frequently Bought Together
ATO/ATC Fuse 20A Yellow
Couldn't load pickup availability
Stepdown Butt Connector 24 to 22/22 to 18 AWG
Couldn't load pickup availability
Female Quick Slide Terminal 16 to 14 AWG Clear
Couldn't load pickup availability
Thermoplastic Plug 2 Pole 3 Wire 15A 125V
Couldn't load pickup availability
Weather Protected Connector Boot 2 Pole 3 Wire 30A
Couldn't load pickup availability
Industrial Duty Plug 20A 125V L5-20P
Couldn't load pickup availability
Self-Drilling Screw Hex Head 1/4-14 x 1"
Couldn't load pickup availability
USS Flat Washer Thru-Hardened Steel 5/16"
Couldn't load pickup availability
Hex Nut Grade 8 Alloy Steel 3/8-16
Couldn't load pickup availability
Universal School Bus Switch SPST 36VDC
Couldn't load pickup availability
Toggle Switch SPST 50A 6V Off-On
Couldn't load pickup availability
Universal Toggle Switch SPST 6A 125V On-Off
Couldn't load pickup availability
Product Description
• Green dot signifies Hospital Grade• 2 pole, 3 wire
• Double-wipe, copper alloy grounding contacts
• One-piece, triple-wipe brass line contacts
• Heavy-duty, copper alloy self-grounding strap
• High-impact, chemical-resistant nylon face and back
• Strip gauge for accurate back wiring
• Heavy-duty, double-plated wraparound steel yoke locked in for maximum strength and security
• Back wiring – eight wiring pockets for convenient feed-through wiring, clamp-type terminals
• Large No. 10 binding head terminal screws fasten wire securely and easily – backed out and staked for fast wiring
• Extra-large green hex head grounding screw for positive grounding
• Break-off tabs for split-circuit wiring
• Thread-cleaning captive mounting screws
• All Lawson Hospital Grade wiring devices conform to OSHA and NEMA specifications and all other safety regulations• Entire device meets or exceeds UL, CSA, NEMA/ANSI and Federal specifications
Technical Specifications
| Item#: | 82551 |
|---|---|
| Style | Hospital Grade Receptacles |
| Volts | 125 |
| Description | Duplex |
| NEMA Configuration | 5-15R |
| Color | Ivory |
| Approvals | UL, CSA, NEMA/ANSI, and Federal Specifications |
| Type | Plugs, Connectors and Receptacles |
| UNSPSC #: | 39121400 |
| TAA Compliant: | No |
| Weight: | 0.22 lb |
