IFI 100/107 Top Locknut, Grade C, Alloy Steel, Zinc/Wax Finish, Coarse Thread, 0.288" Thickness, 7/16" Across Flats, 1/4-20
(Pack of
100)
The Top Locknut Grade C delivers uncompromising reliability when your high-stress applications demand it most. This heat-treated, vibration-resistant locknut maintains its grip through severe conditions that would cause standard nuts to fail, ensuring your critical assemblies stay secure even under extreme vibration and repeated stress cycles. Engineered specifically for Grade 8 applications, it retains its locking torque through a minimum of five reapplications while meeting stringent IFI and ANSI specifications with 150,000 PSI minimum proof strength. Whether you're working on heavy machinery, automotive assemblies, or industrial equipment, this Grade C locknut provides the dependable hold that keeps your work running smoothly and safely.
• Heat-treated for matched strength
• Will not loosen even under severe vibration
• Locking torque is retained for a minimum of five reapplications
• 150,000 PSI minimum proof strength
• Meets IFI and ANSI specifications
• Developed for Grade 8 applications
• Designed for use with Tuff-Torq® Cap Screws
• Identified by six symmetrically spaced marks on the chamfered surface on the top of the nut
NOTE: Not recommended for use above 450°F (232°C).
For recommended torque values, see Lawson’s E546 brochure.
Couldn't load pickup availability
Frequently Bought Together
SAE Flat Washer Thru-Hardened Steel 5/16"
Couldn't load pickup availability
Hex Nut Grade 5 Steel 3/8-16
Couldn't load pickup availability
Hex Nut Grade 8 Alloy Steel 1/4-20
Couldn't load pickup availability
Locknut with Nylon Insert 18-8 SS 3/8-16
Couldn't load pickup availability
Locknut with Nylon Insert 18-8 SS 1/4-20
Couldn't load pickup availability
IFI 100/107 Top Locknut Grade C 5/16-18
Couldn't load pickup availability
IFI 100/107 Top Locknut Grade C 1/2-13
Couldn't load pickup availability
Hex Nut Grade 5 Steel 1/2-13
Couldn't load pickup availability
Hex Nut Grade 8 Steel 3/8-16
Couldn't load pickup availability
Stepdown Butt Connector 22 to 18/16 to 14 AWG
Couldn't load pickup availability
Autobahn Ergo Magna EZ Crimper Ratcheting Terminal Crimper
Couldn't load pickup availability
Cross-Over Socket Extension Set, 3/8" Drive, 3 Piece
Couldn't load pickup availability
BK1 Bearkat Safety Glasses
Couldn't load pickup availability
Plow Bolt High Strength A9 5/8-11 x 2-1/2"
Couldn't load pickup availability
CL1 Checklite Safety Glasses
Couldn't load pickup availability
N9691 Cut Resistant Insulated Gloves
Couldn't load pickup availability
6310 XL Adjustable Ice Traction Device
Couldn't load pickup availability
6310 L Adjustable Ice Traction Device
Couldn't load pickup availability
Product Description
The Top Locknut Grade C delivers uncompromising reliability when your high-stress applications demand it most. This heat-treated, vibration-resistant locknut maintains its grip through severe conditions that would cause standard nuts to fail, ensuring your critical assemblies stay secure even under extreme vibration and repeated stress cycles. Engineered specifically for Grade 8 applications, it retains its locking torque through a minimum of five reapplications while meeting stringent IFI and ANSI specifications with 150,000 PSI minimum proof strength. Whether you're working on heavy machinery, automotive assemblies, or industrial equipment, this Grade C locknut provides the dependable hold that keeps your work running smoothly and safely.• Heat-treated for matched strength
• Will not loosen even under severe vibration
• Locking torque is retained for a minimum of five reapplications
• 150,000 PSI minimum proof strength
• Meets IFI and ANSI specifications
• Developed for Grade 8 applications
• Designed for use with Tuff-Torq® Cap Screws
• Identified by six symmetrically spaced marks on the chamfered surface on the top of the nut
NOTE: Not recommended for use above 450°F (232°C).
For recommended torque values, see Lawson’s E546 brochure.
Technical Specifications
| Item#: | 80927 |
|---|---|
| Diameter | 1/4 " |
| Thread Pitch | 20 |
| Grade | C |
| Finish | Zinc/Wax |
| Type | Top Lock Nut |
| Material | Alloy Steel |
| Thickness | 0.288 " |
| Across Flats | 7/16 " |
| Thread | Coarse |
| Size | 1/4-20 |
| Specifications | IFI 100/107 |
| Maximum Temperature | 450º F |
| Proof | 150,000 PSI |
| UNSPSC #: | 31161716 |
| TAA Compliant: | No |
| Weight: | 0.73 lb |
