Home Circuit Breakers Mid-Range Panel-Mount Circuit Breaker Type III 20A
Circuit Breakers

Mid-Range Panel-Mount Circuit Breaker, Type III Manual Reset, 20 Amps, 30 Volts DC, Rounded Profile Body
(Pack of 1)

Item#: 50258

Lawson Products

• Available in either Type I Automatic Reset or Type III Manual Reset with push-to-trip feature
• Rounded profile body and cover boss allow for 3-hole panel cutout mounting
• Standard mounted centers, 8–32 threaded mounting inserts
• Type III Manual Reset type allows opening the circuit path without disconnecting it from the power source
• Voltage rating: 32V DC, for use on 6V, 12V and 24V systems• Ignition protected (ABYC E-9/SAE J1171)
• For either drop-in or rear access mounting
• Applications include marine, RV and agricultural vehicles

Read More
Check Availability

Catalog page#: 19-14

Frequently Bought Together


ATC Circuit Breaker Type I 30A 12V

Item#: 29854

ATC Circuit Breaker Type I 10A 12V

Item#: 29850

ATC Circuit Breaker Type III 10A 24V

Item#: 29859

Stepdown Butt Connector 22 to 18/16 to 14 AWG

Item#: 1495188

Butt Connector 22 to 18 AWG Red

Item#: 92822

Vision Pro Super

Item#: DY21061040

ATO/ATC Fuse 25A Clear

Item#: 83029

ATO/ATC Fuse 5A Tan

Item#: 83025

MINI Fuse 25A Clear

Item#: 95705

USS Flat Washer Thru-Hardened Steel 3/8"

Item#: 88447

Butt Connector 16 to 14 AWG Blue

Item#: 92823

Nylon Cable Tie 4" Black

Item#: 94609

Product Description

• Available in either Type I Automatic Reset or Type III Manual Reset with push-to-trip feature
• Rounded profile body and cover boss allow for 3-hole panel cutout mounting
• Standard mounted centers, 8–32 threaded mounting inserts
• Type III Manual Reset type allows opening the circuit path without disconnecting it from the power source
• Voltage rating: 32V DC, for use on 6V, 12V and 24V systems• Ignition protected (ABYC E-9/SAE J1171)
• For either drop-in or rear access mounting
• Applications include marine, RV and agricultural vehicles

Technical Specifications

Item#: 50258
Style Mid-Range Panel-Mounted Circuit Breakers
Amperage 20 A
Volts 32 DC
Approvals Ignition protected (ABYC E-9/SAE J1171)
Description Type III Manual Reset
Type Electrical
UNSPSC #: 39121601
TAA Compliant: Yes
Weight: 0.11 lb
