Pilotdrive Cryotap M14 x 2.0 Starter Hand Tap
Pilotdrive Cryotap M14 x 2.0 Starter Hand Tap

Pilotdrive Cryotap M14 x 2.0 Starter Hand Tap
(Pack of 1)

Item#: DY80636024

CryoTool®

• Easiest Starting Tap - CENTERLine™ point firmly lodges in the hole to eliminate tap shifting or wobbling with no guide blocks needed
• Non-Drifting - CENTERLine™ point maintains alignment from start to finish even while hand tapping
• Cryophase™ Treated - Increases tool life and maximizes torsion strength
• Precise - Perfect for tapping thin metals because the first few tapped threads are as clean and precise as the last few tapped threads
Specifications
• Material: High Speed Steel
• Coating: Gold Oxide
• Hardness: 64-66Rc
• Number of Chamfered Threads: 4 to 4-1/2 Threads
• Cryophase™: Thermal cycle cryogenic treatment
• Thread Standard: Exceeds ANSI B1.1
Note: Not intended for depths greater than 1-1/2 times tap diameter.
CAUTION: Any cutting tool may break or shatter under improper use. Government regulations require use of safety glasses and other appropriate safety equipment at all times in the vicinity of use.

Read More
Check Availability

Frequently Bought Together

Jobber Length Drill Bit HSS 31/64

Jobber Length Drill Bit HSS 17/64"

Item#: 84734M06
Mounted Flap Wheel 2

Mounted Flap Wheel 2" 60 Grit

Item#: 92019
Jobber Length Drill Bit HSS 31/64

Jobber Length Drill Bit HSS 7/16"

Item#: 84745
Plier Long Chain Nose with Side Cutter 7-1/2

Plier Long Chain Nose with Side Cutter 7-1/2"

Item#: 97932
CryoBoost 1/4

CryoBoost 1/4" Dia. 1/4" Hex Shank Drill Bit

Item#: DY83611664
Tape Measure 27 Foot, Power Return Tape Measure, 27', Nylon Coated, Auto Locking, Ergonomic

Tape Measure 27 Foot

Item#: DY80000167
Self-Drilling Screw Hex Head #6-20 x 1/2

Self-Drilling Screw Hex Head #10-16 x 3/4"

Item#: 84931
Stepdown Butt Connector 16 to 14/12 to 10 AWG, Stepdown Butt Connector, Crystal Clear Insulation, 16 to 14/12 to 10 AWG, Blue

Stepdown Butt Connector 16 to 14/12 to 10 AWG

Item#: 1495189
Superbutt Connector 22 to 18 AWG Red, Superbutt Connector, Extended Barrel, Red, 22 to 18 AWG, 1.05

Superbutt Connector 22 to 18 AWG Red

Item#: 94727
Pilotdrive Cryotap #10-24 Starter Hand Tap

Pilotdrive Cryotap #10-32 Starter Hand Tap

Item#: DY80635006
HSS Spiral Point Hand Tap 5/8-11, Spiral Point Hand Tap, High Speed Steel, 3 Flute, 5/8-11, 1-3/32

HSS Spiral Point Hand Tap 5/8-11

Item#: 61142
HSS Spiral Point Hand Tap 5/8-18, Spiral Point Hand Tap, High Speed Steel, 3 Flute, 5/8-18, 1-3/32

HSS Spiral Point Hand Tap 5/8-18

Item#: 61143
Cryotap 9/16

Cryotap 1/4"-20 Taper Hand Tap

Item#: DY80631302
HSS Spiral Point Hand Tap M10 x 1.5, Spiral Point Hand Tap, High Speed Steel, 3 Flute, M10 x 1.5, 2-15/16

HSS Spiral Point Hand Tap M10 x 1.5

Item#: 63500
4-Flute HSS Taper Hand Tap 1-1/8-12, Taper Hand Tap, High Speed Steel, Gold Oxide Finish, 4 Flute, 1-1/8-12

4-Flute HSS Bottoming Hand Tap 5/8-11

Item#: 61030
Jobber Length Drill Bit HSS 31/64

Jobber Length Drill Bit HSS 7/64"

Item#: 84724
57Pc Torsion Impact Bit Master Set, 57Pc Torsion S3 Impact Bit Master Set with Case

57Pc Torsion Impact Bit Master Set

Item#: DY81100505
1/4

1/4" Cordless Impact Hex Driver Charging Bundle

Item#: 1638995CB

Product Description

• Easiest Starting Tap - CENTERLine™ point firmly lodges in the hole to eliminate tap shifting or wobbling with no guide blocks needed
• Non-Drifting - CENTERLine™ point maintains alignment from start to finish even while hand tapping
• Cryophase™ Treated - Increases tool life and maximizes torsion strength
• Precise - Perfect for tapping thin metals because the first few tapped threads are as clean and precise as the last few tapped threads
Specifications
• Material: High Speed Steel
• Coating: Gold Oxide
• Hardness: 64-66Rc
• Number of Chamfered Threads: 4 to 4-1/2 Threads
• Cryophase™: Thermal cycle cryogenic treatment
• Thread Standard: Exceeds ANSI B1.1
Note: Not intended for depths greater than 1-1/2 times tap diameter.
CAUTION: Any cutting tool may break or shatter under improper use. Government regulations require use of safety glasses and other appropriate safety equipment at all times in the vicinity of use.

Technical Specifications

Item#: DY80636024
Type Metric
Diameter M14
Pitch 2.0 mm
Flutes 4
Overall Length 3-19/32 "
Recommended Drill Size 12 mm
UNSPSC #: 23241615
TAA Compliant: No
Weight: 0.135 lb
