Power Connector Housing, 2-Wire Plug, 24 Amps, 250 Volts, Nylon
(Pack of
5)
Tin-plated brass terminals
0.093" nylon housings
Friction lock and positive polarization on all housings
Interchangeable with Molex 0.093" connectors
Each connection carries up to 12A (example: A housing with three terminals is rated at 36A)
UL recognized, File No. E29179 CSA certified, File No. LR-19980 250V maximum operating voltage
NOTE: Plugs and Receptacles should be replaced in pairs whenever possible to insure that the plug and receptacle will mate properly.
Couldn't load pickup availability
Frequently Bought Together
Connector Housing 20A 2-Wire Tower
Couldn't load pickup availability
Female Quick Slide Terminal 16 to 14 AWG Clear
Couldn't load pickup availability
Cable Tie 7.31" Black
Couldn't load pickup availability
Power Connector Housing 12-Wire Receptacle
Couldn't load pickup availability
Pin and Socket Connectors 137Pcs
Couldn't load pickup availability
Power Connector Housing 3-Wire Receptacle
Couldn't load pickup availability
Utility Knife, Folding , 4" Closed
Couldn't load pickup availability
Self-Drilling Screw Hex Head 1/4-14 x 1"
Couldn't load pickup availability
USS Flat Washer Thru-Hardened Steel 5/16"
Couldn't load pickup availability
Ring Tongue Terminal 22 to 18 AWG Red
Couldn't load pickup availability
Ring Tongue Terminal 12 to 10 AWG Yellow
Couldn't load pickup availability
Butt Connector 26 to 22 AWG
Couldn't load pickup availability
Product Description
Tin-plated brass terminals 0.093" nylon housings
Friction lock and positive polarization on all housings
Interchangeable with Molex 0.093" connectors
Each connection carries up to 12A (example: A housing with three terminals is rated at 36A)
UL recognized, File No. E29179 CSA certified, File No. LR-19980 250V maximum operating voltage
NOTE: Plugs and Receptacles should be replaced in pairs whenever possible to insure that the plug and receptacle will mate properly.
Technical Specifications
| Item#: | 98801 |
|---|---|
| Type | Plug |
| Maximum Voltage | 250 V |
| Approvals | UL recognized File No. E-29179 and CSA certified, File No. LR-19980 |
| Description | 2 Wire |
| Style | Pin and Socket Plugs |
| UNSPSC #: | 39121432 |
| TAA Compliant: | Yes |
| Weight: | 0.03 lb |
Product Restrictions
