Retaining Ring, External E-Type, 18-8 Stainless Steel, Plain Finish, 1" Shaft Diameter
(Pack of
5)
SKU:59539 Item#: 59539
• Applicable where it is impossible to axially apply an external ring
• Can be used for varying shaft diameters
• May be easily applied and removed with a screwdriver or other simple tool
Couldn't load pickup availability
Frequently Bought Together
Retaining Ring External 18-8 Stainless Steel 32mm
Item#: 41593
Couldn't load pickup availability
Retaining Ring External Steel 25mm
Item#: 97022
Couldn't load pickup availability
Retaining Ring External 18-8 Stainless Steel 18mm
Item#: 41586
Couldn't load pickup availability
Flat Washer Grade 12 Thru-Hardened Steel M6
Item#: 87508
Couldn't load pickup availability
IFI 100/107 Top Locknut Grade C 1/2-13
Item#: 80931
Couldn't load pickup availability
SAE J995C Locknut with Nylon Insert Grade 8 5/8-11
Item#: 53985
Couldn't load pickup availability
Retaining Ring External Steel 3/8"
Item#: 11230
Couldn't load pickup availability
Retaining Ring External Steel 7/16"
Item#: 11231
Couldn't load pickup availability
Retaining Ring Internal Steel 3"
Item#: 92577
Couldn't load pickup availability
SAE J995C Locknut with Nylon Insert Grade 8 1/2-13
Item#: 53983
Couldn't load pickup availability
Self-Drilling Screw Hex Head 1/4-14 x 1"
Item#: 2539
Couldn't load pickup availability
USS Flat Washer Thru-Hardened Steel 5/16"
Item#: FA88446
Couldn't load pickup availability
Product Description
• Applicable where it is impossible to axially apply an external ring• Can be used for varying shaft diameters
• May be easily applied and removed with a screwdriver or other simple tool
Technical Specifications
| Item#: | 59539 |
|---|---|
| Shaft Diameter | 1 " |
| Ring Clearance | 1.500 " |
| Ring Thickness | .050 " |
| Groove Diameter | .835 " |
| Groove Width | .056 " |
| Finish | Plain |
| Type | External Type Retaining Ring |
| Material | Stainless Steel |
| Size | 1 " |
| UNSPSC #: | 31163202 |
| TAA Compliant: | Yes |
| Weight: | 0.07 lb |
