Anchor Shackle, Screw Pin, 3/4", 13,000 lb WLL, Carbon Steel, Orange Powder Coated
(Pack of
2)
SKU:14492 Item#: 14492
Screw pin shackles afford quick and easy removal of the screw pin which is secured by torque. While the threaded pin can resist axial forces, it is vulnerable to backing out and the shackle is not reliable in applications where the pin is subjected to a torque or twisting action.
• Carbon steel bodies
• Alloy steel pins
• Working Load Limit and traceability codes shown as permanent marking on body and pin
• All shackles meet or exceed Federal Specification RRC-271F, Type IVA, Grade A, Class 2
• Design factor 6:1
• Desirable in applications where the shackle is frequently removed
CAUTION: Do not exceed working load limits.
Couldn't load pickup availability
Catalog page#: 15-21
Frequently Bought Together
Spring Link, 3/16", 100 lb WLL, Zinc
Couldn't load pickup availability
Quick Link, Stainless Steel, 3/16", 800 LB WLL
Couldn't load pickup availability
Eye Bolts, Machinery, 3/4 x 2"
Couldn't load pickup availability
Tarp Strap Epdm Rubber with Hooks 35" Long
Couldn't load pickup availability
Wire Rope, Steel, Bare, 7x7, 1/16", 480 lbs Breaking Strength
Couldn't load pickup availability
Tarp Strap Epdm Rubber with Hooks 28" Long
Couldn't load pickup availability
Screw Pin Anchor Shackle, 1/4", 667 lb WLL
Couldn't load pickup availability
Bolt, Nut and Cotter Anchor Shackle, 1", 20,000 lb WLL
Couldn't load pickup availability
Screw Pin Long Shackle, Stainless Steel, 5/16", 1,000 lb WLL
Couldn't load pickup availability
SAE Flat Washer Thru-Hardened Steel 5/16"
Couldn't load pickup availability
Hex Nut Grade 8 Alloy Steel 3/8-16
Couldn't load pickup availability
Self-Drilling Screw Hex Head 1/4-14 x 1"
Couldn't load pickup availability
Product Description
Screw pin shackles afford quick and easy removal of the screw pin which is secured by torque. While the threaded pin can resist axial forces, it is vulnerable to backing out and the shackle is not reliable in applications where the pin is subjected to a torque or twisting action.• Carbon steel bodies
• Alloy steel pins
• Working Load Limit and traceability codes shown as permanent marking on body and pin
• All shackles meet or exceed Federal Specification RRC-271F, Type IVA, Grade A, Class 2
• Design factor 6:1
• Desirable in applications where the shackle is frequently removed
CAUTION: Do not exceed working load limits.
Technical Specifications
| Item#: | 14492 |
|---|---|
| Manufacturer Model #: | M652P |
| Type | Anchor Shackle |
| Style | Screw Pin |
| Body Material | Carbon Steel |
| Finish | Orange Powder Coated |
| Size | 3/4 " |
| Working Load Limit | 13,000 lb |
| Pin Diameter | 7/8 " |
| Pin Material | Alloy Steel |
| Width Between Eyes | 1-1/4 " |
| Bow Width | 1-3/4 " |
| Depth | 2-13/16 " |
| UNSPSC #: | 24101641 |
| TAA Compliant: | Yes |
| Weight: | 4.76 lb |
