Spiraflex Aggie PVC Suction/Discharge Hose, High-Density Rigid Pliovic Helix Reinforcement, Clear/White, 79PSI, 2" ID
(Pack of
100)
A general-purpose water suction hose for use in industrial, agriculture, air seeder and construction applications.
• Tube: Clear Pliovic™
• Reinforcement: High-density white rigid Pliovic™ helix
• Temperature range: 0°F to 158°F (–9°C to +70°C)
Frequently Bought Together
EPDM Suction Hose Assembly 3" x 20' Green
Item#: 41502
Couldn't load pickup availability
EPDM Suction Hose Assembly 2" x 20' Green
Item#: 41497
Couldn't load pickup availability
EPDM Suction Hose Assembly 1-1/2" x 20' Green
Item#: 41500
Couldn't load pickup availability
Air Master® Diving Umbilical 3/8" ID X 1,000' Length, Black
Item#: 1645976
Couldn't load pickup availability
Air Master® Diving Umbilical 3/8" ID X 600' Length, Black
Item#: 1645977
Couldn't load pickup availability
Air Master® Diving Umbilical 1/2" ID X 50' Length, Black
Item#: 1645972
Couldn't load pickup availability
Non-Perforated Clamp 316 SS #4 7/16 to 11/16"
Item#: 58832
Couldn't load pickup availability
Miniature Clamp SS 5/16 to 7/8"
Item#: 86723
Couldn't load pickup availability
DOT Connector Male Brass 1/4 x 1/8-27
Item#: 91785
Couldn't load pickup availability
Self-Drilling Screw Hex Head #10-16 x 3/4"
Item#: 84931
Couldn't load pickup availability
Flat Washer Grade 12 Thru-Hardened Steel M12
Item#: 87512
Couldn't load pickup availability
USS Flat Washer Thru-Hardened Steel 3/8"
Item#: FA88447
Couldn't load pickup availability
Product Description
A general-purpose water suction hose for use in industrial, agriculture, air seeder and construction applications.• Tube: Clear Pliovic™
• Reinforcement: High-density white rigid Pliovic™ helix
• Temperature range: 0°F to 158°F (–9°C to +70°C)
Technical Specifications
| Item#: | 42446 |
|---|---|
| Type | Suction and Discharge |
| Manufacturer Series Number | 586-453 |
| Manufacturer Series Name | Spiraflex Aggie PVC |
| I.D. | 2 " |
| Dash Size | 2 (-32) |
| Working Pressure | 79 PSI |
| Minimum Bend Radius | 8 |
| Inner Tube Material | Pliovic |
| Hose Reinforcement | High-Density White Rigid Pliovic Helix |
| Hose Cover Material | Pliovic Helix |
| Temperature | 0F to 158F |
| Color | Clear/White |
| Size | -32 x 100 |
| Length | 100 |
| Weight per Foot | 0.58 |
| Material Number | 20013500 |
| UNSPSC #: | 40142000 |
| TAA Compliant: | Yes |
Product Restrictions
