Step-Down Butt Connector, Insulated, 16 to 14/22 to 18 AWG, 1.5" Length, Red
(Pack of
10)
SKU:KT13697 Item#: KT13697
• Seal and protect electrical connections against failure due to water, moisture, corrosion, vibration and strain
• Dual wall heat shrink tubing pre-shrunk around an electro-tin-plated copper butt splice
• The inner wall adhesive hot-melts into the wire insulation to encapsulate and seal the connection
• Outer wall shrinks to provide strength with flexibility
• Unaffected by most oils, fuels, solvents, chemicals and road salts
• Color-coded, semi-transparent insulation for excellent crimping every time
• Self-seals if accidentally punctured prior to heating
• Tensile strength: 3,200 PSI minimum
• Elongation: 200% minimum• Working voltage: 600V
• Continuous operating temperature: –67°F to +230°F (–55°C to +110°C)
• Minimum shrink temperature: 248°F (120°C)
• Butt connectors have a unique, double-thick insulation for burial, water-exposed, high-stress and vibration applications
