Terminal Crimping Tool with Interchangeable Die, 22-10 AWG, Full Cycle Ratchet, Suitable for Insulated Terminals
(Pack of
1)
SKU:95109 Item#: 95109
• Professional tool incorporating a single frame with several interchangeable dies
• Full cycle ratchet with safety release
• High-quality electrical and mechanical crimps are made simultaneously
• Crimps meet or exceed industry standards
• Assures a positive mechanical and electrical crimp and ease of use
• Crimping dies can be easily switched with two screws
The die will slide out towards the front of the frame simply by loosening the two socket head screws and removing them.
To replace the die1. Simply extend the frame to its full open position.2. Close the frame approximately halfway. 3. Insert the die into the frame until it stops. All dies can be inserted only one way for the tool to close properly.4. Tighten the screws approximately halfway. 5. Close the frame to press the dies against each other. This helps to align the dies in the frame.6. Finish tightening the screws. 7. Frame and tool are complete and ready for use.
Couldn't load pickup availability
Catalog page#: 17-72
Frequently Bought Together
Battery Terminal Crimper Tool For 6 to 4/0 Gauge
Couldn't load pickup availability
Terminal Crimp Frame
Couldn't load pickup availability
Quick Connect Crimping Tool 26-6 AWG
Couldn't load pickup availability
Autobahn Ergo Magna EZ Crimper Ratcheting Terminal Crimper
Couldn't load pickup availability
10" Forman's Favorite Heavy-Duty Copper & Aluminum Cable Cutter Pliers
Couldn't load pickup availability
Stingray Mini Butane Torch Self-Igniting
Couldn't load pickup availability
Autobahn Ergo Magna EZ Crimper Ratcheting Terminal Crimper
Couldn't load pickup availability
2Pc Index-Tend Pry Bar Set
Couldn't load pickup availability
3" Pneumatic Cut-Off Tool
Couldn't load pickup availability
Nylon Cable Tie 8" Black
Couldn't load pickup availability
Nylon Cable Tie 15.25" Black
Couldn't load pickup availability
Nylon Cable Tie 11.75" Black
Couldn't load pickup availability
Cross-Over Socket Extension Set, 3/8" Drive, 3 Piece
Couldn't load pickup availability
Autobahn Ergo Magna EZ Crimper Ratcheting Terminal Crimper
Couldn't load pickup availability
Utility Knife, Folding , 4" Closed
Couldn't load pickup availability
Product Description
• Professional tool incorporating a single frame with several interchangeable dies• Full cycle ratchet with safety release
• High-quality electrical and mechanical crimps are made simultaneously
• Crimps meet or exceed industry standards
• Assures a positive mechanical and electrical crimp and ease of use
• Crimping dies can be easily switched with two screws
The die will slide out towards the front of the frame simply by loosening the two socket head screws and removing them.
To replace the die1. Simply extend the frame to its full open position.2. Close the frame approximately halfway. 3. Insert the die into the frame until it stops. All dies can be inserted only one way for the tool to close properly.4. Tighten the screws approximately halfway. 5. Close the frame to press the dies against each other. This helps to align the dies in the frame.6. Finish tightening the screws. 7. Frame and tool are complete and ready for use.
Technical Specifications
| Item#: | 95109 |
|---|---|
| Type | Crimping Tool |
| Style | Terminal Connector Crimping System |
| Crimp Range | 22-10 AWG |
| Description | Tool with 95103 Die |
| UNSPSC #: | 27111500 |
| TAA Compliant: | Yes |
| Weight: | 1.85 lb |
