Vinyl Electrical Tape, Orange, 3/4" Width, 66' Length, 220% Elongation, 14 to 176°F Temperature Rating
(Pack of
1)
SKU:90237 Item#: 90237
Protect and insulate your electrical work with our electrical tape. This black vinyl tape is ideal for all wire and cable splices rated up to 600 volts and 221°F (105°C). Perfect for demanding electrical maintenance and repair jobs in automotive, communications and manufacturing industries. Turn to this professional-grade tape preferred by electricians.
• 600V
• Flame-retardant
• Tested in accordance with UL, ASTM and CSA standards
• 3/4" x 60'
• 7 mil thick (except 54519, which is 8 mil)
Frequently Bought Together
Socket Contact 20-16 AWG Size 16
Couldn't load pickup availability
ATO/ATC Fuse 30A Green
Couldn't load pickup availability
Connector Housing 20A 2-Wire Tower
Couldn't load pickup availability
SAE J995C Locknut with Nylon Insert Grade 8 5/8-11
Couldn't load pickup availability
Interchangeable Hex Bit Set 20Pc Torx
Couldn't load pickup availability
SAE Flat Washer Thru-Hardened Steel 1/2"
Couldn't load pickup availability
Vinyl Electrical Tape Gray 3/4" x 66'
Couldn't load pickup availability
Silifuse Identification Tape, Black, 1 In Width x .02 Thick x 10Ft Len
Couldn't load pickup availability
Vinyl Electrical Tape Orange 3/4" x 66'
Couldn't load pickup availability
Tru-Shrink Heat Shrink Tubing 20 to 18 AWG Black
Couldn't load pickup availability
Rubber Grommet 3/4" ID
Couldn't load pickup availability
Split Wire Loom Polyethylene Black 0.625" ID 25'
Couldn't load pickup availability
Product Description
Protect and insulate your electrical work with our electrical tape. This black vinyl tape is ideal for all wire and cable splices rated up to 600 volts and 221°F (105°C). Perfect for demanding electrical maintenance and repair jobs in automotive, communications and manufacturing industries. Turn to this professional-grade tape preferred by electricians.• 600V
• Flame-retardant
• Tested in accordance with UL, ASTM and CSA standards
• 3/4" x 60'
• 7 mil thick (except 54519, which is 8 mil)
Technical Specifications
| Item#: | 90237 |
|---|---|
| Type | Individual Roll |
| Style | Vinyl Electrical Tape |
| Color | Orange |
| Dielectric Strength | 1,000 V/mm |
| Length | 66 ft |
| Width | 3/4 " |
| Thickness | 7 mil |
| Temperature Range | 14 to 176 °F |
| Celcius Temperature Range | -10 to 80 °C |
| Elongation | 220 % |
| Adhesion to Steel | 21 in. oz. |
| Adhesion to Backing | 20 in. oz. |
| Breaking Strength | 19 in·lbf |
| Voltage Rating | 600 V |
| Approvals | UL, CSA, ASTM |
| Description | Cold and Weather-Resistant |
| UNSPSC #: | 31201502 |
| TAA Compliant: | No |
| Weight: | 0.18 lb |
