Wire Nut Posi-Twist 22-10 AWG, Wire Nut Posi-Twist, 22-10 AWG
Wire Nut Posi-Twist 22-10 AWG, Wire Nut Posi-Twist, 22-10 AWG

Wire Nut Posi-Twist, 22-10 AWG
(Pack of 10)

Item#: DY20780022

Lawson Products

• A wire nut style connector that creates a secure connection without the use of tools, tape, crimping or soldering
• Simply strip the wires, twist together, insert into the Posi-Twist™ and hand tighten
• The patented design locks wires between two cone shapes when hand-tightened for a connection with exceptional pull-out strength
• The connectors are completely insulated and re-usable
• Connects 2–8 wires depending on the AWG
• Maximum Temperature Rating: 248˚F/ 120˚C

Read More
Check Availability

Frequently Bought Together

Master Series Penlight Flashlight, 500 Lumen Penlight Flashlight, Orange, LED, Aluminum, Waterproof, Impact Resistant

Master Series Penlight Flashlight

Item#: 1635602
ATO/ATC Fuse 15A Blue, ATO/ATC Fuse with Element Indicator, Blue, 15 Amps, Heat-resistant Plastic

ATO/ATC Fuse 15A Blue

Item#: 84789
Butt Connector 12 to 10 AWG Yellow, Butt Connector, 2-Piece Heat Seal, Polyolefin Insulated, 12 to 10 AWG, 1.64

Butt Connector 12 to 10 AWG Yellow

Item#: 92824
Waterproof Work Aqua Light 66 LED, Waterproof Aqua Light, 66 LED, Blue, 18-7/8

Waterproof Work Aqua Light 66 LED

Item#: DY80000105
IFI 100/107 Top Locknut Grade C 1-8, IFI 100/107 Top Locknut, Grade C, Alloy Steel, Zinc/Wax Finish, Coarse Thread

IFI 100/107 Top Locknut Grade C 5/8-11

Item#: 80933
Locknut with Nylon Insert Grade 8 5/16-24, Locknut with Nylon Insert, Grade 8, Alloy Steel, Yellow Zinc Finish, Fine Thread

Locknut with Nylon Insert Grade 8 5/16-18

Item#: 53980
Ring Tongue Terminal 16 to 14 AWG Blue, Ring Tongue Terminal, 2-Piece Heat Seal, Polyolefin Insulated, 16 to 14 AWG

Ring Tongue Terminal 16 to 14 AWG Blue

Item#: 92809
Female Quick Slide Terminal 16 to 14 AWG Blue, Female Quick Slide Terminal, 3-Piece Heat Seal, Fully Insulated, Nylon

Female Quick Slide Terminal 16 to 14 AWG Blue

Item#: 89463
Male Quick Slide Terminal 22 to 18 AWG Clear, Male Quick Slide Disconnector, Fully Insulated, 22 to 18 AWG, 1/4

Male Quick Slide Terminal 22 to 18 AWG Clear

Item#: 1495182
Wire Connector Assortment 410Pcs, Wire Connector Assortment, 13 Items, 410 Pieces

Wire Connector Assortment 410Pcs

Item#: LP408BL
Sure-Lok Wire Connector 22 to 12 AWG Yellow, Sure-Lok Wire Connector, 22 to 12 AWG, 600/1000 Volts, Yellow

Sure-Lok Wire Connector 22 to 12 AWG Yellow

Item#: P35026
Wire Nut Twister 22-12 AWG Tan, Wire Nut Twister, 22-12 AWG, 600 Volts, Tan

Wire Nut Twister 22-12 AWG Tan

Item#: DY20701000
Wire Nut Posi-Twist 24-14 AWG, Wire Nut Posi-Twist, 24-14 AWG

Wire Nut Posi-Twist 24-14 AWG

Item#: DY20780024
Reusable Posi-Lock Butt Connector 10-12 AWG Wire Yellow, Reusable Posi-Lock Butt Connector, 10-12 AWG Wire, Yellow

Reusable Posi-Lock

Item#: DY20060810
Posi-lock Splice Connector 18 to 12 AWG, Posi-lock Splice Connector, 18 to 12 AWG, 482°F Temperature Rating

Posi-lock Splice Connector 18 to 12 AWG

Item#: 59771

Product Description

• A wire nut style connector that creates a secure connection without the use of tools, tape, crimping or soldering
• Simply strip the wires, twist together, insert into the Posi-Twist™ and hand tighten
• The patented design locks wires between two cone shapes when hand-tightened for a connection with exceptional pull-out strength
• The connectors are completely insulated and re-usable
• Connects 2–8 wires depending on the AWG
• Maximum Temperature Rating: 248˚F/ 120˚C

Technical Specifications

Item#: DY20780022
Type Wire Nut
Wire Gauge 22-10 AWG
Voltage Rating 600 V
Color Red
Maximum Temperature Rating 248˚F/ 120˚C
Approvals SAE J1211
Description Red Posi-Twist Wire Nut 22-10 AWG
Style Posi-Twist™ Connectors
UNSPSC #: 39121409
TAA Compliant: No
Weight: 0.06 lb
