Wire Thread Insert Repair Kit, 17 Pieces, 6-32, 304 Stainless Steel, 200000PSI Tensile Strength
(Pack of
1)
• Helically-wound thread repair – universally accepted and most cost-effective method of thread repair
• Manufactured from precision cold-formed 18-8 (Type 304) stainless steel
• Kits contain tap, inserts, installation tool, tang removal tool (select kits) and instructions, packaged in a sturdy and convenient storage box
• Inserts compensate for pitch and angle errors and share the load over more of the thread for stronger assemblies
• Tensile strength of at least 200,000 PSI
• Wide effective temperature range: –275°F to +774°F (–170°C to +412°C)
Fix-A-Thred® Insert Installation Instructions
Drill to clear out the damaged thread (if necessary).
Thread insert tap supplied. Tap thread should match up with bolt.
Wind insert in with light downward pressure until 1/4 to 1/2 turn below surface, driving tang towards bottom of the hole.
Remove tool and sit back on top of tang. Tap down sharply. Do not try to twist tang off. For large fine threads, use long nose pliers and pull tang out.
To insure proper installation of inserts, always use the correct and corresponding tools.
Frequently Bought Together
Stemmed Crimped Wire Wheel 2"
Couldn't load pickup availability
Premium Grinding Wheel 4-1/2"
Couldn't load pickup availability
Jobber Length Drill Bit HSS 25/64"
Couldn't load pickup availability
Locknut with Nylon Insert Grade 8 5/16-18
Couldn't load pickup availability
SAE Flat Washer Thru-Hardened Steel 5/16"
Couldn't load pickup availability
Superbutt Connector 16 to 14 AWG Blue
Couldn't load pickup availability
Spiral Fluted Screw Extractor 3/16 to 1/4"
Couldn't load pickup availability
Spiral Fluted Screw Extractor 3/4 to 1"
Couldn't load pickup availability
Spiral Fluted Screw Extractor 9/16 to 3/4"
Couldn't load pickup availability
Jobber Length Drill Bit HSS 1/8"
Couldn't load pickup availability
Mounted Flap Wheel 2"
Couldn't load pickup availability
Twist-On Surface Conditioning Disc 3" Brown
Couldn't load pickup availability
Wire Thread Insert Repair Kit 3/4-16
Couldn't load pickup availability
Wire Thread Insert Repair Kit 1/2-20
Couldn't load pickup availability
Wire Thread Insert Repair Kit 5-40
Couldn't load pickup availability
Product Description
• Helically-wound thread repair – universally accepted and most cost-effective method of thread repair• Manufactured from precision cold-formed 18-8 (Type 304) stainless steel
• Kits contain tap, inserts, installation tool, tang removal tool (select kits) and instructions, packaged in a sturdy and convenient storage box
• Inserts compensate for pitch and angle errors and share the load over more of the thread for stronger assemblies
• Tensile strength of at least 200,000 PSI
• Wide effective temperature range: –275°F to +774°F (–170°C to +412°C)
Fix-A-Thred® Insert Installation Instructions
Drill to clear out the damaged thread (if necessary).
Thread insert tap supplied. Tap thread should match up with bolt.
Wind insert in with light downward pressure until 1/4 to 1/2 turn below surface, driving tang towards bottom of the hole.
Remove tool and sit back on top of tang. Tap down sharply. Do not try to twist tang off. For large fine threads, use long nose pliers and pull tang out.
To insure proper installation of inserts, always use the correct and corresponding tools.
Technical Specifications
| Item#: | 61224 |
|---|---|
| Type | Insert Repair Kit |
| Size | 6-32 |
| Recommended Drill Size | No. 25 |
| Number of Pieces | 17 |
| UNSPSC #: | 27112810 |
| TAA Compliant: | Yes |
| Weight: | 0.45 lb |
