Wire Thread Insert Repair Kit, 8 Pieces, M14-2, 304 Stainless Steel, 200000PSI Tensile Strength
(Pack of
1)
• Helically-wound thread repair – universally accepted and most cost-effective method of thread repair
• Manufactured from precision cold-formed 18-8 (Type 304) stainless steel
• Kits contain tap, inserts, installation tool, tang removal tool (select kits) and instructions, packaged in a sturdy and convenient storage box
• Inserts compensate for pitch and angle errors and share the load over more of the thread for stronger assemblies
• Tensile strength of at least 200,000 PSI
• Wide effective temperature range: –275°F to +774°F (–170°C to +412°C)
Fix-A-Thred® Insert Installation Instructions
Drill to clear out the damaged thread (if necessary).
Thread insert tap supplied. Tap thread should match up with bolt.
Wind insert in with light downward pressure until 1/4 to 1/2 turn below surface, driving tang towards bottom of the hole.
Remove tool and sit back on top of tang. Tap down sharply. Do not try to twist tang off. For large fine threads, use long nose pliers and pull tang out.
To insure proper installation of inserts, always use the correct and corresponding tools.
Frequently Bought Together
Jobber Length Drill Bit HSS 5/64"
Couldn't load pickup availability
1/2" Fractional Drill Bit, Jobber Length, W/Flats
Couldn't load pickup availability
Jobber Length Drill Bit HSS 11/64"
Couldn't load pickup availability
SAE Flat Washer Thru-Hardened Steel 5/8"
Couldn't load pickup availability
Stepdown Butt Connector 16 to 14/12 to 10 AWG
Couldn't load pickup availability
Self-Drilling Screw Hex Head #10-16 x 3/4"
Couldn't load pickup availability
Tapered Flute Screw Extractor 7/16 to 1/2"
Couldn't load pickup availability
SS Locking Thread Insert M10 x 1.5
Couldn't load pickup availability
Wire Thread Insert Repair Kit 5/16-18
Couldn't load pickup availability
7" Straight Jaw Locking Pliers
Couldn't load pickup availability
3/8" Fractional Drill Bit, Jobber Length, W/Flats
Couldn't load pickup availability
Jobber Length Drill Bit HSS 13/32"
Couldn't load pickup availability
Wire Thread Insert Repair Kit M12-1.75
Couldn't load pickup availability
Wire Thread Insert Repair Kit 10-24
Couldn't load pickup availability
Product Description
• Helically-wound thread repair – universally accepted and most cost-effective method of thread repair• Manufactured from precision cold-formed 18-8 (Type 304) stainless steel
• Kits contain tap, inserts, installation tool, tang removal tool (select kits) and instructions, packaged in a sturdy and convenient storage box
• Inserts compensate for pitch and angle errors and share the load over more of the thread for stronger assemblies
• Tensile strength of at least 200,000 PSI
• Wide effective temperature range: –275°F to +774°F (–170°C to +412°C)
Fix-A-Thred® Insert Installation Instructions
Drill to clear out the damaged thread (if necessary).
Thread insert tap supplied. Tap thread should match up with bolt.
Wind insert in with light downward pressure until 1/4 to 1/2 turn below surface, driving tang towards bottom of the hole.
Remove tool and sit back on top of tang. Tap down sharply. Do not try to twist tang off. For large fine threads, use long nose pliers and pull tang out.
To insure proper installation of inserts, always use the correct and corresponding tools.
Technical Specifications
| Item#: | 53850 |
|---|---|
| Type | Insert Repair Kit |
| Size | M14 x 2.0 |
| Recommended Drill Size | 37/64 " |
| Number of Pieces | 8 |
| UNSPSC #: | 27112810 |
| TAA Compliant: | Yes |
| Weight: | 0.8 lb |
