Hex Cap Screw Grade 2 5/8-11 x 5"
(Pack of
25.0)
• UNC threads
• Also for use as a high-grade machine bolt
• SAE-approved cold-forming steel
• Full diameter shank
• Rolled threads
• Manufactured to SAE Grade 2 specifications
• Class 2A thread fit
Minimum Threaded Length – Up to 6" Long: (2 x Diameter) + 1/4" Over 6" Long: (2 x Diameter) + 1/2
Couldn't load pickup availability
California Proposition 65: Not Applicable
www.P65Warnings.ca.gov
Catalog page#: 3-25
Frequently Bought Together
Product Description
• UNC threads• Also for use as a high-grade machine bolt
• SAE-approved cold-forming steel
• Full diameter shank
• Rolled threads
• Manufactured to SAE Grade 2 specifications
• Class 2A thread fit
Minimum Threaded Length – Up to 6" Long: (2 x Diameter) + 1/4" Over 6" Long: (2 x Diameter) + 1/2
Technical Specifications
| Item#: | 4081 |
|---|---|
| Style | Standard |
| Diameter | 5/8 " |
| Thread Pitch | 11 |
| Thread | Coarse |
| Length | 5 " |
| Type | Hex Cap Screw |
| Across Flats | 15/16 " |
| Material | Carbon Steel |
| Grade | 2 |
| Finish | Bright Zinc |
| Tensile Strength | 74,000 PSI |
| Head Style | Hex |
| Head Height | 25/64 " |
| Thread Form | UNR |
| Thread Length | Partial |
| Thread Length Minimum | 1-1/2 " |
| UNSPSC #: | 31161501 |
| TAA Compliant: | No |
| Weight: | 11.62 lb |
