Mild Steel Stick Electrode Chematized Flux / Moisture Proof/Polarity Dc Or Ac 1/8"
(Pack of
2)
SKU:EG10694002 Item#: EG10694002
Dura-Weld Gold has a special Chem-A-Tized2 flux coating that provides the best all-position performance of any steel electrode and allows it to operate at lower amperages. The flux has cleaning agents that remove oxides and contaminates from the weld, including rust, grease and paint… it even welds through water.
• Moisture proof flux – guaranteed to never go bad when stored
• Superior all-position weldability with the exclusive Chem-A-Tized2 process
• Welds contaminated steel – less pre-cleaning and weld clean-up
• Very easy to use – practically welds by itself with little or no-spatter
• Tensile strength: Up to 83,000 psi/572 Mpa
• Yield strength: 69,000 psi/476 Mpa
• Elongation: 25%
• Machinability: Excellent
• Hardness: 85 Rb
• Impact: 20 ft-lbs.
• Current: DC or AC
Remove cracked or fatigued metal by grinding or gouging with Arc-Prep #161 electrode. Bevel heavy sections before welding. Use AC or DC current. Use a contact or a minimum arc length with a weave or stringer bead technique. Pass-over-pass can be used without chipping slag in multi-pass welds. Allow to cool slowly.
