Home Hydraulics Hose and Tubing Accessories Reels Air/Water Hose Reel 1/2" x 100'
Accessories
Super HubT Air/Water Hose Reel 1/2
Super HubT Air/Water Hose Reel 1/2

Standard Truck Mount Air/Water Hose Reel, Double Axle Support to Center Shaft, 300PSI, 95lbs, 1/2" x 100'
(Pack of 1)

Item#: 20783

Coxreels®

EZ-Coil® Patented Safety Recoil Mechanism
• Retracts hose at rates up to 80% slower than conventional reels
• Significantly reduces potential for hose whip injuries and damage
Super Hub™ Axle Support System Features
• Double axle support to center shaft
• 1" solid steel axle with lubricated precision bearings
• Increased stability during operation for reduced vibration and higher reel strength
Truck-Mounted Reels
• Super Hub™-equipped with triple axle support to center shaft
• 1" solid steel axle with lubricated precision bearings
• Increased stability during operation for reduced vibration and higher reel strength
Standard Features
• Compact design
• Heavy gauge 1/4" steel base and support post
• Factory matched cartridge style spring motor
• Brass NPT swivel inlet machined from solid brass
• Nitrile swivel seals
• 1" solid steel axle with lubricated precision bearings
• High-quality air hose provided (unless otherwise specified)

Read More

California Proposition 65: WARNING: Cancer and Reproductive Harm -
www.P65Warnings.ca.gov

Catalog page#: 8-145

Frequently Bought Together

AG-Lite Rubber Water Hose Reel Heavy Duty Single Arm Assembly 3/4

AG-Lite Rubber Water Hose Reel Heavy Duty Single Arm Assembly 3/4" x 50'

Item#: 1690532
OilShield Rubber Air Hose Reel Heavy Duty Single Arm Assembly 1/2

OilShield Rubber Air Hose Reel Heavy Duty Single Arm Assembly 1/2" x 50'

Item#: 1690616
Rubber Air Hose Reel Dual Arm Assembly 3/8

Rubber Air Hose Reel Dual Arm Assembly 3/8" x 100'

Item#: 1690587
FLEXAIR 3/8

FLEXAIR 1/2" I.D. x 50' air hose

Item#: 1637166
Super HubT Air/Water Hose Reel 1/2

Super HubT Air/Water Hose Reel 1/2" x 50'

Item#: 20777
Air/Multipurpose Rubber Hose 3/8

Air/Multipurpose Rubber Hose 3/8" Black

Item#: 64730
DOT Elbow Male Nylon 3/8 x 1/4-18, DOT Air Brake Push to Connect Elbow, Male, Nylon, 3/8 x 1/4-18, Tube x Pipe

DOT Elbow Male Nylon 3/8 x 1/4-18

Item#: 91797
Hose Clamp 304 SS 2-13/16 to 3-3/4

Hose Clamp 304 SS 1-13/16 to 2-3/4"

Item#: 87142
Hose Clamp 304 SS 2-13/16 to 3-3/4

Hose Clamp 304 SS 3/4 to 1-3/4"

Item#: 86728
Super HubT Air/Water Hose Reel 1/2

EZ-Coil Air/Water Hose Reel 3/8" x 75'

Item#: 20781
Super HubT Air/Water Hose Reel 1/2

Super HubT EZ-Coil Air/Water Hose Reel 1/2" x 50'

Item#: 20778
Super HubT Air/Water Hose Reel 1/2

Super HubT EZ-Coil Air/Water Hose Reel 3/8" x 50'

Item#: 20776
AG-Lite Rubber Water Hose Reel Heavy Duty Single Arm Assembly 3/4

AG-Lite Rubber Water Hose Reel Heavy Duty Single Arm Assembly 3/4" x 50'

Item#: 1690532
OilShield Rubber Air Hose Reel Heavy Duty Single Arm Assembly 1/2

OilShield Rubber Air Hose Reel Heavy Duty Single Arm Assembly 1/2" x 50'

Item#: 1690616
Rubber Air Hose Reel Dual Arm Assembly 3/8

Rubber Air Hose Reel Dual Arm Assembly 3/8" x 100'

Item#: 1690587
SAE Flat Washer Thru-Hardened Steel 5/16

SAE Flat Washer Thru-Hardened Steel 5/16"

Item#: 88436
Self-Drilling Screw Hex Head #6-20 x 1/2

Self-Drilling Screw Hex Head 1/4-14 x 1"

Item#: 2539
USS Flat Washer Thru-Hardened Steel 5/16

USS Flat Washer Thru-Hardened Steel 5/16"

Item#: FA88446

Product Description

EZ-Coil® Patented Safety Recoil Mechanism
• Retracts hose at rates up to 80% slower than conventional reels
• Significantly reduces potential for hose whip injuries and damage
Super Hub™ Axle Support System Features
• Double axle support to center shaft
• 1" solid steel axle with lubricated precision bearings
• Increased stability during operation for reduced vibration and higher reel strength
Truck-Mounted Reels
• Super Hub™-equipped with triple axle support to center shaft
• 1" solid steel axle with lubricated precision bearings
• Increased stability during operation for reduced vibration and higher reel strength
Standard Features
• Compact design
• Heavy gauge 1/4" steel base and support post
• Factory matched cartridge style spring motor
• Brass NPT swivel inlet machined from solid brass
• Nitrile swivel seals
• 1" solid steel axle with lubricated precision bearings
• High-quality air hose provided (unless otherwise specified)

Technical Specifications

Item#: 20783
Manufacturer Model #: TSH-N-4100
Industrial / Hydraulic Industrial
Type Hose Reels - Air/Water
Description Standard Truck-Mount Air Hose Reel
Category / Performance Good
Size 1/2x100
Length 100 ft
Manufacturer Series Name T Series
I.D. 1/2 "
Working Pressure 300 PSI
Cox Part Number TSH-N-4100
Quantity Per Package 1.0000
UNSPSC #: 40142022
TAA Compliant: Yes
