Home Material Handling Roller Chain and Tools Links Connecting Link, Double Strand, Steel, Industry No. 80-2
Links
Connecting Link, Double Strand, Steel, Industry No. 80-2, 1
Connecting Link, Double Strand, Steel, Industry No. 80-2, 1

Connecting Link, Double Strand, Steel, Industry No. 80-2, 1" Pitch, 35,200lbs Average Tensile Strength
(Pack of 5)

Item#: 1593434

Daido®

Connecting Link, Double Strand, Steel, Industry No. 80-2, 1" Pitch, 35,200lbs Average Tensile Strength

Read More
Check Availability

Frequently Bought Together

Connecting Link, Single Strand, Steel, Industry No. 06B, 3/8

Connecting Link, Single Strand, Steel, Industry No. 06B

Item#: 1443464
Offset Link (Half Link), Single Strand, Heavy, Steel, Industry No. 100H, 1-1/4

Offset Link (Half Link), Single Strand, Heavy, Steel, Industry No. 80H

Item#: 1443416
Connecting Link, Double Pitch, A-Type, Steel, Industry No. A 2060, 1-1/2

Connecting Link, Double Pitch, A-Type, Steel, Industry No. A 2060

Item#: 85378
Screw Pin Anchor Shackle, 3/8

Screw Pin Anchor Shackle, 1/2", 6,000 lb WLL

Item#: 1429885
Tarp Strap Epdm Rubber with Hooks 28

Tarp Strap Epdm Rubber with Hooks 14" Long

Item#: 99560
Screw Pin Anchor Shackle, 3/8

Screw Pin Anchor Shackle, 1/4", 1,500 lb WLL

Item#: 1429877
Offset Link (Half Link), Single Strand, Steel, Industry No. 06B, 3/8

Offset Link (Half Link), Single Strand, Steel, Industry No. 06B

Item#: 1443412
Roller Chain, Single Strand, Steel, Industry No. 60, 3/4'' Pitch, 9,900 lbs Average Tensile Strength

Roller Chain, Single Strand, Steel, Industry No. 60

Item#: 85358
Roller Chain, Single Strand, Steel, Industry No. 60, 3/4'' Pitch, 9,900 lbs Average Tensile Strength

Roller Chain, Single Strand, Steel, Industry No. 40

Item#: 85355
Flat Washer Property Class 10.9 M22, Flat Washer, Property Class 10.9, Carbon Steel, M22

Flat Washer Grade 12 Thru-Hardened Steel M8

Item#: 87510
USS Flat Washer Thru-Hardened Steel 1/4

USS Flat Washer Thru-Hardened Steel 1/4"

Item#: FA88445
Cross-Over Socket Extension Set, 3/4

Cross-Over Socket Extension Set, 3/8" Drive, 3 Piece

Item#: DY89320050

Product Description

Connecting Link, Double Strand, Steel, Industry No. 80-2, 1" Pitch, 35,200lbs Average Tensile Strength

Technical Specifications

Item#: 1593434
Manufacturer Model #: CL80-2C
Configuration Connecting Link
Type Double Strand
Style Standard
Material Steel
Finish Plain
Industry Number 80-2
Pitch 1 "
Roller Width 0.625 "
Roller Diameter 0.625 "
Plate Thickness 0.126 "
Plate Height 0.945 "
Minimum Tensile Strength 32,120 lb
Average Tensile Strength 35,200 lb
Maximum Load 5,610 lb
UNSPSC #: 31163027
TAA Compliant: Yes
Weight: 1.305 lb
