Home Material Handling Roller Chain and Tools Links Connecting Link, Single Strand, Ultimate Power, Steel, Industry No. 80
Links
Offset Link (Half Link), Single Strand, Ultimate Power, Steel, Industr, Offset Link (Half Link), Single Strand
Offset Link (Half Link), Single Strand, Ultimate Power, Steel, Industr, Offset Link (Half Link), Single Strand

Connecting Link, Single Strand, Ultimate Power, Steel, Industry No. 80HK, 1" Pitch, 21,560lbs Average Tensile Strength
(Pack of 5)

Item#: 1443429

Daido®

Conform to the heavy type of the ANSI roller chain. Their inner and outer plates are equal in thickness to those of the next larger size of standard roller chain.
• Approximately 20% higher tensile strength
• Approximately 15% higher maximum allowable load
• Heavy-duty applications at low speeds

Read More

Catalog page#: 15-61

Frequently Bought Together

Offset Link (Half Link), Single Strand, Ultimate Power, Steel, Industr, Offset Link (Half Link), Single Strand

Offset Link (Half Link), Single Strand, Ultimate Power, Steel, Industr

Item#: 1443499
Connecting Link, Single Strand, Steel, Industry No. 10B, 5/8

Connecting Link, Single Strand, Steel, Industry No. 10B

Item#: 1443386
Offset Link (Half Link), Double Strand, Steel, Industry No. 12B-2, 3/4

Offset Link (Half Link), Double Strand, Steel, Industry No. 12B-2

Item#: 57045
Screw Pin Anchor Shackle, 5/8

Screw Pin Anchor Shackle, 3/8", 2,000 lb WLL

Item#: 1424880
Wire Rope, Steel, Nylon Coated, 7x7, 3/32

Wire Rope, Steel, Nylon Coated, 7x7, 1/16", 480 lbs Breaking Strength

Item#: 1439061
Double Clevis (Mid-Link), 7/16

Double Clevis (Mid-Link), 3/8", 6,600 lb WLL

Item#: 81642
Connecting Link, Double Strand, Steel, Industry No. 80-2, 1

Connecting Link, Double Strand, Steel, Industry No. 80-2

Item#: 1593434
Connecting Link, Double Pitch-Conveyor, Steel, Nickel Plated, Industry No. C2042, 1

Connecting Link, Double Pitch-Conveyor, Steel, Nickel Plated, Industry

Item#: 1443537
Connecting Link, Double Strand, Steel, Nickel Plated, Industry No. 50-2, 5/8

Connecting Link, Double Strand, Steel, Nickel Plated, Industry No. 50-

Item#: 1443506
Hex Nut Grade 8 Alloy Steel 1-8, ANSI B18.2.2 Hex Nut, Grade 8, Alloy Steel, Zinc Finish, Coarse Thread, 1-1/2

Hex Nut Grade 8 Alloy Steel 3/8-16

Item#: A102
Hex Nut Grade 8 Alloy Steel 1-8, ANSI B18.2.2 Hex Nut, Grade 8, Alloy Steel, Zinc Finish, Coarse Thread, 1-1/2

Hex Nut Grade 8 Alloy Steel 1/4-20

Item#: A100
Flat Washer Property Class 10.9 M22, Flat Washer, Property Class 10.9, Carbon Steel, M22

Flat Washer Grade 12 Thru-Hardened Steel M12

Item#: 87512

Product Description

Conform to the heavy type of the ANSI roller chain. Their inner and outer plates are equal in thickness to those of the next larger size of standard roller chain.
• Approximately 20% higher tensile strength
• Approximately 15% higher maximum allowable load
• Heavy-duty applications at low speeds

Technical Specifications

Item#: 1443429
Manufacturer Model #: CL80HKC
Configuration Connecting Link
Type Single Strand
Style Extra-Heavy
Material Steel
Finish Plain
Industry Number 80HK
Pitch 1 "
Roller Width 0.625 "
Roller Diameter 0.625 "
Plate Thickness 0.157 "
Plate Height 0.945 "
Minimum Tensile Strength 18,260 lb
Average Tensile Strength 21,560 lb
Maximum Load 3,740 lb
UNSPSC #: 31163027
TAA Compliant: Yes
Weight: 0.81 lb
