DT Series Plug, 13 Amps, 12 Contacts, Contact Size 16
(Pack of
1)
SKU:29499 Item#: 29499
Ensure seamless and secure connections, even in the toughest conditions, with the DT Series Plug. Designed to excel in cable-to-cable, cable-to-board, and cable-to-device applications, this environmentally-sealed connector offers reliability and durability that automotive and industrial professionals can count on. With a current rating of 13 Amps, a wide temperature range from -67°F to +257°F, and a dielectric strength of 1,500V, the DT Series Plug is engineered to perform under extreme circumstances. Whether you're tackling demanding automotive repairs or industrial installations, this connector simplifies the job while ensuring the safety and longevity of your work.
• Contact size: 16
• Current rating: 13 Amps
• Temperature range: –67°F to +257°F (–55°C to +125°C)
• Dielectric strength: 1,500V minimum
• DT Series (Deutsch); AT Series (Amphenol)
Couldn't load pickup availability
Frequently Bought Together
Energizer® AA Alkaline Battery 1.5V
Couldn't load pickup availability
Cable Seal Green 20-18 AWG 20A 12V
Couldn't load pickup availability
ATO/ATC Fuse 30A Green
Couldn't load pickup availability
2-Way Inline Connection Kit 16-14 AWG
Couldn't load pickup availability
Straight Barrel Battery Terminal 2/0 AWG Positive
Couldn't load pickup availability
Sealing Plug 16-12 AWG 13A Contact Size 16/12
Couldn't load pickup availability
Lock Washer Alloy Steel 3/8"
Couldn't load pickup availability
Qwik Stik® Electrolyte Powder Mix Grape
Couldn't load pickup availability
Hex Nut Grade 8 Alloy Steel 5/16-18
Couldn't load pickup availability
Pigtail Assembly Connector 2-Wire Shroud Female
Couldn't load pickup availability
Pin Contact 20 AWG Size 20
Couldn't load pickup availability
Socket Contact 20 AWG Size 20
Couldn't load pickup availability
Product Description
Ensure seamless and secure connections, even in the toughest conditions, with the DT Series Plug. Designed to excel in cable-to-cable, cable-to-board, and cable-to-device applications, this environmentally-sealed connector offers reliability and durability that automotive and industrial professionals can count on. With a current rating of 13 Amps, a wide temperature range from -67°F to +257°F, and a dielectric strength of 1,500V, the DT Series Plug is engineered to perform under extreme circumstances. Whether you're tackling demanding automotive repairs or industrial installations, this connector simplifies the job while ensuring the safety and longevity of your work.• Contact size: 16
• Current rating: 13 Amps
• Temperature range: –67°F to +257°F (–55°C to +125°C)
• Dielectric strength: 1,500V minimum
• DT Series (Deutsch); AT Series (Amphenol)
Technical Specifications
| Item#: | 29499 |
|---|---|
| Style | DT Series |
| Connection Type | Plug |
| Number of Contacts | 12 |
| UNSPSC #: | 39121432 |
| TAA Compliant: | No |
| Weight: | 0.03 lb |
