Home Hydraulics Fittings Brass Forged Body Ball Valve Brass 1/4-18 x 1/4-18
Brass
Forged Body Ball Valve Brass 2 x 2
Forged Body Ball Valve Brass 2 x 2

Forged Body Ball Valve, Brass, 1/4-18 x 1/4-18, Female NPT x Female NPT, 600PSI
(Pack of 1)

Item#: 63134

Lawson Products

For use in gas and pneumatic lines, this Forged Body Ball Valve is ideal for high-pressure and high-temperature applications where reliability and safety are important. Made of brass with dual sealing system that allows valve to be operated in either direction making installation easier. Other advantages include no metal-to-metal moving parts, a handle clearly showing ball position and no maintenance requirements.
• 24-hour 100% seal test guaranteed
• Working pressure: 600 PSI
• Operating temperature: –40°F to +350°F
• Chrome plated brass ball for longer life
• Silicone-free lubricant on all seals
• Approvals: CSA, FM, UL, CUL, Federal Specification WW-V-35C
Applications:
• Gas
• Pneumatic lines
• Travel stops on body to avoid stresses at stem
• Hot forged, sand blasted, unplated brass body and cap sealed with Loctite® or equivalent thread sealant
• Finest brass according to EN 12165 and EN 12164 specifications
• Full port to DIN 3357 for maximum flow
• NPT taper ANSI B.1.20.1 female by female threads
• Blowout-proof nickel plated brass stem
• Two FPM O-rings at the stem for maximum safety
• Geomet® carbon steel handle with thick PVC dip coating for thermal and electrical protection
• Handle removable with valve in service
• Pure PTFE self-lubricating seats with flexible-lip design

Read More
Check Availability

California Proposition 65: WARNING: Cancer and Reproductive Harm -
www.P65Warnings.ca.gov

Catalog page#: 9-25

Frequently Bought Together

Pipe Bushing Brass 1/2-14 x 1/8-27, Pipe Bushing, Brass, 1/2-14 x 1/8-27, Male NPT x Female NPT, 1200PSI

Pipe Bushing Brass 1/2-14 x 1/4-18

Item#: 5286
Hex Head Plug Brass 1/2-14 Male NPT, Hex Head Plug, Brass, 1/2-14 Male NPT, 1200PSI

Hex Head Plug Brass 3/8-18 Male NPT

Item#: 5364
Pipe Bushing Brass 1/2-14 x 1/8-27, Pipe Bushing, Brass, 1/2-14 x 1/8-27, Male NPT x Female NPT, 1200PSI

Pipe Bushing Brass 3/8-18 x 1/4-18

Item#: 5284
Weatherhead H280 Hydraulic Hose Rubber 0.53

Weatherhead H280 Hydraulic Hose Rubber 0.69" x 50'

Item#: 50799 06
Weatherhead H280 Hydraulic Hose Rubber 0.53

Weatherhead H280 Hydraulic Hose Rubber 1.41" x 50'

Item#: 50799 16
Weatherhead H280 Hydraulic Hose Rubber 0.53

Weatherhead H280 Hydraulic Hose Rubber 0.94" x 50'

Item#: 50799 10
Diamond Texture Premium Nitrile Gloves, Black, 8 Mil, Large, 1,000/Case, Diamond Texture Premium Nitrile Gloves, Black

Premium Nitrile Gloves, Black, 6 Mil, X-Large, 100/Box

Item#: 1418069
Weatherhead H280 Hydraulic Hose Rubber 0.53

Weatherhead H280 Hydraulic Hose Rubber 0.69" x 50'

Item#: 50799 06
Weatherhead H280 Hydraulic Hose Rubber 0.53

Weatherhead H280 Hydraulic Hose Rubber 1.41" x 50'

Item#: 50799 16
Pipe Bushing Brass 1/2-14 x 1/8-27, Pipe Bushing, Brass, 1/2-14 x 1/8-27, Male NPT x Female NPT, 1200PSI

Pipe Bushing Brass 1/2-14 x 1/4-18

Item#: 5286
Hex Head Plug Brass 1/2-14 Male NPT, Hex Head Plug, Brass, 1/2-14 Male NPT, 1200PSI

Hex Head Plug Brass 3/8-18 Male NPT

Item#: 5364
Pipe Bushing Brass 1/2-14 x 1/8-27, Pipe Bushing, Brass, 1/2-14 x 1/8-27, Male NPT x Female NPT, 1200PSI

Pipe Bushing Brass 3/8-18 x 1/4-18

Item#: 5284
Pipe Bushing Brass 1/2-14 x 1/8-27, Pipe Bushing, Brass, 1/2-14 x 1/8-27, Male NPT x Female NPT, 1200PSI

Pipe Bushing Brass 1/2-14 x 3/8-18

Item#: 5287
Miniature Clamp SS 7/32 to 5/8

Miniature Clamp SS 7/32 to 5/8"

Item#: 86738
DOT Union Nylon 1/4 x 1/4

DOT Union Nylon 1/4 x 1/4"

Item#: 91819
Nylon Cable Tie 15.25

Nylon Cable Tie 15.25" Black

Item#: 94613
Nylon Cable Tie 15.25

Nylon Cable Tie 11.75" Black

Item#: 94611
Nylon Cable Tie 15.25

Nylon Cable Tie 15.5" Black

Item#: 94612
DOT Union Nylon 1/4 x 1/4

DOT Union Nylon 1/4 x 1/4"

Item#: 91819
DOT Union Brass 3/8 x 3/8

DOT Union Brass 3/8 x 3/8"

Item#: 57500
Qwik Stik Electrolyte Powder Mix Grape, Qwik Stiks Electrolyte Powder Drink Mix, Grape, 50 0.11 oz Packets

Qwik Stik® Electrolyte Powder Mix Grape

Item#: SF12394

Product Description

For use in gas and pneumatic lines, this Forged Body Ball Valve is ideal for high-pressure and high-temperature applications where reliability and safety are important. Made of brass with dual sealing system that allows valve to be operated in either direction making installation easier. Other advantages include no metal-to-metal moving parts, a handle clearly showing ball position and no maintenance requirements.
• 24-hour 100% seal test guaranteed
• Working pressure: 600 PSI
• Operating temperature: –40°F to +350°F
• Chrome plated brass ball for longer life
• Silicone-free lubricant on all seals
• Approvals: CSA, FM, UL, CUL, Federal Specification WW-V-35C
Applications:
• Gas
• Pneumatic lines
• Travel stops on body to avoid stresses at stem
• Hot forged, sand blasted, unplated brass body and cap sealed with Loctite® or equivalent thread sealant
• Finest brass according to EN 12165 and EN 12164 specifications
• Full port to DIN 3357 for maximum flow
• NPT taper ANSI B.1.20.1 female by female threads
• Blowout-proof nickel plated brass stem
• Two FPM O-rings at the stem for maximum safety
• Geomet® carbon steel handle with thick PVC dip coating for thermal and electrical protection
• Handle removable with valve in service
• Pure PTFE self-lubricating seats with flexible-lip design

Technical Specifications

Item#: 63134
Fitting Type Ball Valve
Configuration Forged Body for Gas Lines
Material Brass
Connection Type A x B Female NPT x Female NPT
Fitting Dimension A 1/4-18
Fitting Dimension B 1/4-18
Working Pressure 600 PSI
Temperature Range -40 to 350 °F
UNSPSC #: 40170000
TAA Compliant: No
Weight: 0.34 lb
