Forged Body Ball Valve Brass 2 x 2
Forged Body Ball Valve Brass 2 x 2

Forged Body Ball Valve, Brass, 3/4 x 3/4", Female NPT x Female NPT, 600PSI
(Pack of 1)

Item#: 63137

Lawson Products

For use in gas and pneumatic lines, this Forged Body Ball Valve is ideal for high-pressure and high-temperature applications where reliability and safety are important. Made of brass with dual sealing system that allows valve to be operated in either direction making installation easier. Other advantages include no metal-to-metal moving parts, a handle clearly showing ball position and no maintenance requirements.
• 24-hour 100% seal test guaranteed
• Working pressure: 600 PSI
• Operating temperature: –40°F to +350°F
• Chrome plated brass ball for longer life
• Silicone-free lubricant on all seals
• Approvals: CSA, FM, UL, CUL, Federal Specification WW-V-35C
Applications:
• Gas
• Pneumatic lines
• Travel stops on body to avoid stresses at stem
• Hot forged, sand blasted, unplated brass body and cap sealed with Loctite® or equivalent thread sealant
• Finest brass according to EN 12165 and EN 12164 specifications
• Full port to DIN 3357 for maximum flow
• NPT taper ANSI B.1.20.1 female by female threads
• Blowout-proof nickel plated brass stem
• Two FPM O-rings at the stem for maximum safety
• Geomet® carbon steel handle with thick PVC dip coating for thermal and electrical protection
• Handle removable with valve in service
• Pure PTFE self-lubricating seats with flexible-lip design

Read More
Check Availability

California Proposition 65: WARNING: Cancer and Reproductive Harm -
www.P65Warnings.ca.gov

Catalog page#: 9-25

Frequently Bought Together

Hex Head Plug Brass 1/2-14 Male NPT, Hex Head Plug, Brass, 1/2-14 Male NPT, 1200PSI

Hex Head Plug Brass 1/8-27 Male NPT

Item#: 5362
Pipe Tee Brass 1/4-18 x 1/4-18 x 1/4-18, Pipe Tee, Brass, 1/4-18 x 1/4-18 x 1/4-18, Female NPT x Female NPT x Female NPT

Pipe Tee Brass 1/4-18 x 1/4-18 x 1/4-18

Item#: 5326
Pipe Close Nipple Brass 1/8-27 x 1/8-27, Pipe Close Nipple, Brass, 1/8-27 x 1/8-27, Male NPT x Male NPT, 3/4

Pipe Close Nipple Brass 3/8-18 x 3/8-18

Item#: 5299
Z Series Crimp-On Hose End 1/2

Z Series Crimp-On Hose End 3/4" x 1-1/16-12

Item#: 16623
Hydraulic Quick Connect Coupler 1/4

Hydraulic Quick Connect Coupler 1/2" x 3/4-14

Item#: 29972
DOT Swivel Elbow Male 90° Brass 3/8 x 1/2-14, DOT Air Brake Push to Connect Swivel Elbow, 90°, Male, Brass, 3/8 x 1/2-14

DOT Swivel Elbow Male 360° Brass 3/8 x 3/8-18

Item#: 27206
Hydraulic Quick Connect Nipple Steel 1/2

Hydraulic Quick Connect Nipple 3/4" x 1-11-1/2

Item#: 29978
Z Series Crimp-On Hose End 1/2

Z Series Crimp-On Hose End 3/4" x 1-1/16-12

Item#: 16623
Hydraulic Quick Connect Coupler 1/4

Hydraulic Quick Connect Coupler 1/2" x 3/4-14

Item#: 29972
Hex Bushing Steel 3/8-18 x 3/8-18, Hex Bushing, Steel, Black, Schedule 40/80, 3/8-18 x 3/8-18, Male NPT x Female NPT, 150 PSI

Hex Bushing Steel 3/4-14 x 1/2-14

Item#: 8666
Hex Head Plug Brass 1/2-14 Male NPT, Hex Head Plug, Brass, 1/2-14 Male NPT, 1200PSI

Hex Head Plug Brass 1/8-27 Male NPT

Item#: 5362
Hex Bushing Steel 3/8-18 x 3/8-18, Hex Bushing, Steel, Black, Schedule 40/80, 3/8-18 x 3/8-18, Male NPT x Female NPT, 150 PSI

Hex Bushing Steel 1/2-14 x 3/8-18

Item#: 8664
Hose Clamp 304 SS 2-13/16 to 3-3/4

Hose Clamp 304 SS 1-5/16 to 2-1/4"

Item#: 86730
Ball Check Grease Fitting Straight, Ball Check Grease Fitting, Straight, Hardened Steel, 1/4-28 Tapered Thread, 1/2

Ball Check Grease Fitting Straight

Item#: 6202
DOT Connector Male Brass 3/8 x 3/8-18, DOT Air Brake Push to Connect Connector, Male, Brass, 3/8 x 3/8-18, Tube x Pipe

DOT Connector Male Brass 1/4 x 1/8-27

Item#: 57504
USS Flat Washer Thru-Hardened Steel 1/4

USS Flat Washer Thru-Hardened Steel 1/4"

Item#: FA88445
Flat Washer Property Class 10.9 M22, Flat Washer, Property Class 10.9, Carbon Steel, M22

Flat Washer Grade 12 Thru-Hardened Steel M8

Item#: 87510
Cross-Over Socket Extension Set, 3/4

Cross-Over Socket Extension Set, 3/8" Drive, 3 Piece

Item#: DY89320050
Qwik Stik Electrolyte Powder Mix 0 Cal Berry, Hydration Product, Mixed Berry Zero Qwik Stiks Powder Dry Mix, 0.11 Oz

Qwik Stik® Electrolyte Powder Mix 0 Cal Berry

Item#: SF10404
DOT Union Brass 3/8 x 3/8

DOT Union Brass 5/8 x 5/8"

Item#: 27177
Qwik Stik Electrolyte Powder Mix 0 Cal Lemon-Lime, Hydration Product, Lemon-Lime Zero Qwik Stiks Powder Dry Mix, 0.11 Oz

Qwik Stik® Electrolyte Powder Mix 0 Cal Lemon-Lime

Item#: SF10441

Product Description

For use in gas and pneumatic lines, this Forged Body Ball Valve is ideal for high-pressure and high-temperature applications where reliability and safety are important. Made of brass with dual sealing system that allows valve to be operated in either direction making installation easier. Other advantages include no metal-to-metal moving parts, a handle clearly showing ball position and no maintenance requirements.
• 24-hour 100% seal test guaranteed
• Working pressure: 600 PSI
• Operating temperature: –40°F to +350°F
• Chrome plated brass ball for longer life
• Silicone-free lubricant on all seals
• Approvals: CSA, FM, UL, CUL, Federal Specification WW-V-35C
Applications:
• Gas
• Pneumatic lines
• Travel stops on body to avoid stresses at stem
• Hot forged, sand blasted, unplated brass body and cap sealed with Loctite® or equivalent thread sealant
• Finest brass according to EN 12165 and EN 12164 specifications
• Full port to DIN 3357 for maximum flow
• NPT taper ANSI B.1.20.1 female by female threads
• Blowout-proof nickel plated brass stem
• Two FPM O-rings at the stem for maximum safety
• Geomet® carbon steel handle with thick PVC dip coating for thermal and electrical protection
• Handle removable with valve in service
• Pure PTFE self-lubricating seats with flexible-lip design

Technical Specifications

Item#: 63137
Fitting Type Ball Valve
Configuration Forged Body for Gas Lines
Material Brass
Connection Type A x B Female NPT x Female NPT
Fitting Dimension A 3/4-14
Fitting Dimension B 3/4-14
Working Pressure 600 PSI
Temperature Range -40 to 350 °F
UNSPSC #: 40170000
TAA Compliant: No
Weight: 0.66 lb
