H0106 Bosflex Air and Water Hose, EPDM Inner Tube, 2-Spiral Hose Reinforcement, Heat-Resistant, Red, 200PSI, 3/8" ID
(Pack of
50)
SKU:41329 06 Item#: 41329 06
• Advantages:
– Age, abrasion- and water-resistant
– Heat-resistant
– Economical
• Agency Ratings: N/A
• Fittings Certified:
– U-Series
– Inserted Hose Ends: Standard Hose Barbs, Claw-Type Quick Acting, Short or Long Shank Inserts
• Agency Approvals: N/A
• Construction:– Inner Tube: EPDM– Reinforcement: Fiber, 2- or 4-spiral or two braid– Cover: EPDM
• Color: Red or black
• Temperature Range: –40°F to +180°F (–40°C to +82°C)
• Application Notes:
– Spraying and conveying water-based liquid fertilizers and pesticides
– Transfer of air and water
• Markets:
– Agriculture
– Assembly/manufacturers
– Construction
– Food industry
– Metalworking
– Mining
– Oil industry
– Paper/pulp
– Shipbuilding
Couldn't load pickup availability
Catalog page#: 8-143
Frequently Bought Together
Air/Multipurpose Hose 3/8" Black
Couldn't load pickup availability
FLEXAIR 3/8" I.D. x 50' air hose assembly w/ ARO 210 safety coupler
Couldn't load pickup availability
FLEXAIR 1/2" I.D. x 50' air hose assembly w/ Industrial safety coupler
Couldn't load pickup availability
Avagard PU Recoil Air Hose Assembly 3/8" x 25'
Couldn't load pickup availability
Avagard Rubber Air Hose Assembly 3/8" x 25'
Couldn't load pickup availability
Avagard Rubber Air Hose Assembly 3/8" x 100'
Couldn't load pickup availability
DOT Compression Union Brass 1/4"
Couldn't load pickup availability
Hose Clamp 304 SS 3/4 to 1-3/4"
Couldn't load pickup availability
Z Series Crimp-On Hose End 1/2 x 3/4-16"
Couldn't load pickup availability
Hex Nut Grade 8 Alloy Steel 3/8-16
Couldn't load pickup availability
Self-Drilling Screw Hex Head 1/4-14 x 1"
Couldn't load pickup availability
Hex Nut Grade 8 Alloy Steel 1/4-20
Couldn't load pickup availability
Product Description
• Advantages:– Age, abrasion- and water-resistant
– Heat-resistant
– Economical
• Agency Ratings: N/A
• Fittings Certified:
– U-Series
– Inserted Hose Ends: Standard Hose Barbs, Claw-Type Quick Acting, Short or Long Shank Inserts
• Agency Approvals: N/A
• Construction:– Inner Tube: EPDM– Reinforcement: Fiber, 2- or 4-spiral or two braid– Cover: EPDM
• Color: Red or black
• Temperature Range: –40°F to +180°F (–40°C to +82°C)
• Application Notes:
– Spraying and conveying water-based liquid fertilizers and pesticides
– Transfer of air and water
• Markets:
– Agriculture
– Assembly/manufacturers
– Construction
– Food industry
– Metalworking
– Mining
– Oil industry
– Paper/pulp
– Shipbuilding
Technical Specifications
| Item#: | 41329 06 |
|---|---|
| Manufacturer Model #: | H010606RD |
| Type | Air and Multipurpose |
| Manufacturer Series Number | H0106 |
| Manufacturer Series Name | Bosflex A/W |
| Dash Size | -6 |
| Working Pressure | 200 PSI |
| Hose I.D. | 3/8 " |
| Hose O.D. | 11/16 " |
| Inner Tube Material | EPDM |
| Hose Reinforcement | 2-Spiral |
| Hose Cover Material | EPDM |
| Temperature Range | -40F to +180 F |
| Color | Red |
| Quantity Per Package | 50.0000 |
| UNSPSC #: | 40142009 |
| TAA Compliant: | No |
| Weight: | 7.44 lb |
