Hex Nut Grade 8 Steel 1/4-20
(Pack of
100.0)
• Zinc-plated unless noted
• Controlled hardness
• Washer-faced
• Conform to ANSI B18.2.2 and SAE J995 specifications
• Burr-free Class 2B threads
Couldn't load pickup availability
California Proposition 65: Not Applicable
www.P65Warnings.ca.gov
Catalog Page#: 3-26
Frequently Bought Together
SAE Flat Washer Thru-Hardened Steel 3/8"
Couldn't load pickup availability
SAE Flat Washer Thru-Hardened Steel 1/4"
Couldn't load pickup availability
Hex Cap Screw Grade 8 Alloy Steel 3/8-16 x 1-1/2"
Couldn't load pickup availability
Hex Nut Grade 5 Steel 1/2-13
Couldn't load pickup availability
Hex Nut Grade 8 Alloy Steel 3/4-10
Couldn't load pickup availability
Hex Nut Grade 8 Steel 1/2-13
Couldn't load pickup availability
Hex Nut Grade 8 Alloy Steel 5/8-11
Couldn't load pickup availability
SAE J995C Locknut with Nylon Insert Grade 8 5/8-11
Couldn't load pickup availability
Hex Nut Grade 8 Alloy Steel 1/4-20
Couldn't load pickup availability
Nylon Cable Tie 4" Black
Couldn't load pickup availability
High Solids Paints Gloss Black
Couldn't load pickup availability
USS Flat Washer Thru-Hardened Steel 5/16"
Couldn't load pickup availability
Product Description
• Zinc-plated unless noted• Controlled hardness
• Washer-faced
• Conform to ANSI B18.2.2 and SAE J995 specifications
• Burr-free Class 2B threads
Technical Specifications
| Item#: | FA68400 |
|---|---|
| Diameter | 1/4 " |
| Thread Pitch | 20 |
| Type | Hex Nut |
| Grade | 8 |
| Finish | Yellow Zinc |
| Material | Carbon Steel |
| Thickness | 7/32 " |
| Across Flats | 7/16 " |
| Thread | Coarse |
| Size | 1/4-20 " |
| Specifications | ANSI B18.2.2 |
| UNSPSC #: | 31161727 |
| TAA Compliant: | No |
| Weight: | 0.69 lb |
