Hospital Grade Angle Plug 20A 125V
(Pack of 1.0)

Lawson Products

• Green dot signifies Hospital Grade
• 2 pole, 3 wire
• Assembly and cord-grip screws install from front to avoid accidental energizing of hand-held portion of plug
• Non-metallic cord grip firmly grips power cord assuring maximum strain relief – accepts three-conductor cords 0.300" – 0.655" dia.
• Clamp-type terminals for quick, solid connections; terminal screws are color-coded for easy identification
• Individual wire pockets allow maximum conductor separation to prevent flash-over between wires
• Strip gauge for accurate wiring
• No exposed metal parts on hand-held side
• Rugged all-nylon construction
• Transparent wiring chamber and cover for visual inspection
• Dead-front construction prevents accidental contact with live parts
Angle plug can be assembled in any one of twelve positions; wall hugging 90° angle cord exit allows you to keep cords neat and out of the way; interlocking teeth prevent cover from rotating on plug body when cord is pulled
• All Lawson Hospital Grade wiring devices conform to OSHA and NEMA specifications and all other safety regulations

• Meets or exceeds UL, CSA, NEMA/ANSI and Federal standards

Check Availability

Quantity

California Proposition 65: Not Applicable
www.P65Warnings.ca.gov

Catalog Page#: 17-87

Frequently Bought Together

Product Description

Technical Specifications

Item#:	87213
Style	Hospital Grade Plugs and Connectors
Volts	125
Description	Angle Plug
NEMA Configuration	5-20P
Cord Diameter	0.300 - 0.655 "
Approvals	UL, CSA, NEMA, ANSI and Federal standards
Type	Bushings, Plugs, and Connectors
UNSPSC #:	39121400
TAA Compliant:	No
Weight:	0.1 lb
