Hydraulic Quick Connect Nipple, Brass, Unvalved, 3/8" x 3/8-18, Male NPTF, 1.43" Length, 300PSI
(Pack of
2)
SKU:55832 Item#: 55832
These couplers and nipples are designed exclusively for coolant lines to molds and dies on injection molding machinery, and are engineered to significantly reduce downtime by providing fast, easy connection of coolant lines during mold changes.
• Couplers are non-valved and provide maximum flow for efficient cooling• Use in conjunction with Lawson’s Barb-Lok hose and pipe fittings for superior performance
• All sizes are pressure rated to 200 PSI
Dixon: CM-SeriesParker: Mold MateFoster: FJTHansen: Flo-Temp
Couldn't load pickup availability
California Proposition 65: WARNING: Cancer and Reproductive Harm -
www.P65Warnings.ca.gov
Catalog page#: 8-86
Frequently Bought Together
Face Seal O-Ring Buna-N 0.364 x 0.07"
Couldn't load pickup availability
Weatherhead H280 Hydraulic Hose Rubber 0.81" x 50'
Couldn't load pickup availability
Push On Tapered Cap/Plug Polyethylene 1/4"
Couldn't load pickup availability
Crimp-On Hose Coupling 3/8" x 9/16-18
Couldn't load pickup availability
Constant Torque Hose Clamp SS 2-1/4 to 3-1/8"
Couldn't load pickup availability
Z Series Crimp-On Hose End 1/2 x 3/4-16"
Couldn't load pickup availability
Hydraulic Quick Connect Coupler 1/4" x 1/4-18
Couldn't load pickup availability
Hydraulic Quick Connect Nipple Steel 1" x 1-11-1/2
Couldn't load pickup availability
Coupler, ISO16028, 1/2" Body, 1/2"- 14 Female NPTF, Steel
Couldn't load pickup availability
SAE Flat Washer Thru-Hardened Steel 5/8"
Couldn't load pickup availability
Hex Nut Grade 8 Alloy Steel 1/4-20
Couldn't load pickup availability
Flat Washer Grade 12 Thru-Hardened Steel M10
Couldn't load pickup availability
Product Description
These couplers and nipples are designed exclusively for coolant lines to molds and dies on injection molding machinery, and are engineered to significantly reduce downtime by providing fast, easy connection of coolant lines during mold changes.• Couplers are non-valved and provide maximum flow for efficient cooling• Use in conjunction with Lawson’s Barb-Lok hose and pipe fittings for superior performance
• All sizes are pressure rated to 200 PSI
Dixon: CM-SeriesParker: Mold MateFoster: FJTHansen: Flo-Temp
Technical Specifications
| Item#: | 55832 |
|---|---|
| Hydraulic / Pneumatic | Hydraulic |
| Description | Quick Coupling |
| Type | Nipple |
| Style | Unvalved |
| Body Size | 3/8 " |
| Thread Size | 3/8-18 |
| Thread Style | Male NPTF |
| Burst Pressure | 14,500 PSI |
| Seal Material | Silicone |
| Material | Brass |
| Flow | 9 gal/min |
| Length | 1.43 " |
| Temperature Range | -90 to 400 F |
| Working Pressure | 300 PSI |
| Hex Size | 11/16 " |
| Maximum Diameter | 0.79 " |
| UNSPSC #: | 27121701 |
| TAA Compliant: | No |
| Weight: | 0.17 lb |
