Inverted Flare Connector Brass 1/8-27 x 3/8"
(Pack of
10.0)
• Meets SAE hydraulic tube fittings standards as well as ASA and ASME codes for pressure piping• Compatible tubing: Copper, brass, aluminum and welded steel tubing that can be flared• Pressure depends on tubing used. Will stand burst pressure of standard tube – up to 5,000 PSI with double-flared and 3,500 PSI with copper tube• Temperature range: –65°F to +250°F (–54°C to +121°C)
• Applications: Automotive brake, oil and fuel lines; LP and natural gas connections; hazardous liquids; air, water, fuel, oil or non-corrosive gaseous chemicals
Couldn't load pickup availability
California Proposition 65: WARNING: Cancer and Reproductive Harm -
www.P65Warnings.ca.gov
Catalog Page#: 9-18
Frequently Bought Together
Drain Cock External Seat Brass 1/4-18
Couldn't load pickup availability
Forged Body Ball Valve Brass 1/4-18 x 1/4-18
Couldn't load pickup availability
Hex Head Plug Brass 3/4-14 Male NPT
Couldn't load pickup availability
Pipe Street Elbow Brass 45° 1/4-18 x 1/4-18
Couldn't load pickup availability
Pipe Hex Nipple Brass 1/4-18 x 1/4-18
Couldn't load pickup availability
Hex Bushing Steel 1/4-18 x 1/8-27
Couldn't load pickup availability
DOT Connector Male Brass 3/8 x 1/4-18
Couldn't load pickup availability
DOT Connector Male Brass 1/4 x 1/8-27
Couldn't load pickup availability
DOT Swivel Elbow Male 360° Brass 1/4 x 1/8-27
Couldn't load pickup availability
Cable Tie 7.31" Black
Couldn't load pickup availability
Hex Cap Screw Grade 8 Alloy Steel 1/4-20 x 1"
Couldn't load pickup availability
SAE J995C Locknut with Nylon Insert Grade 8 3/8-16
Couldn't load pickup availability
Product Description
• Meets SAE hydraulic tube fittings standards as well as ASA and ASME codes for pressure piping• Compatible tubing: Copper, brass, aluminum and welded steel tubing that can be flared• Pressure depends on tubing used. Will stand burst pressure of standard tube – up to 5,000 PSI with double-flared and 3,500 PSI with copper tube• Temperature range: –65°F to +250°F (–54°C to +121°C)• Applications: Automotive brake, oil and fuel lines; LP and natural gas connections; hazardous liquids; air, water, fuel, oil or non-corrosive gaseous chemicals
Technical Specifications
| Item#: | 5232 |
|---|---|
| Fitting Type | Inverted Flare |
| Configuration | Male Connector |
| Material | Brass |
| Connection Type A x B | Male NPT x Tube |
| Fitting Dimension A | 1/8-27 |
| Fitting Dimension B | 3/8 " |
| Working Pressure | 500 PSI |
| Temperature Range | -65 to 250 F |
| UNSPSC #: | 40170000 |
| TAA Compliant: | No |
| Weight: | 0.55 lb |
