Mid-Range Panel-Mount Circuit Breaker, Type III Manual Reset, 15 Amps, 30 Volts DC, Rounded Profile Body
(Pack of
1)
SKU:50257 Item#: 50257
• Available in either Type I Automatic Reset or Type III Manual Reset with push-to-trip feature
• Rounded profile body and cover boss allow for 3-hole panel cutout mounting
• Standard mounted centers, 8–32 threaded mounting inserts
• Type III Manual Reset type allows opening the circuit path without disconnecting it from the power source
• Voltage rating: 32V DC, for use on 6V, 12V and 24V systems• Ignition protected (ABYC E-9/SAE J1171)
• For either drop-in or rear access mounting
• Applications include marine, RV and agricultural vehicles
Couldn't load pickup availability
Catalog page#: 19-14
Frequently Bought Together
Mid-Range Panel-Mount Circuit Breaker Type I 30A
Couldn't load pickup availability
Post-Style Circuit Breaker with Bracket 20A 12V
Couldn't load pickup availability
Plug-In Circuit Breaker Type II 15A
Couldn't load pickup availability
Tru-Shrink Heat Shrink Tubing 14 to 6 AWG Black
Couldn't load pickup availability
DT Series Receptacle 13A 2 Contacts
Couldn't load pickup availability
Connector Housing 20A 2-Wire Shroud
Couldn't load pickup availability
ATO/ATC Fuse 15A Blue
Couldn't load pickup availability
MINI Smart Glow Fuse 20A Yellow
Couldn't load pickup availability
ATO/ATC Fuse 10A Red
Couldn't load pickup availability
Flat Washer Grade 12 Thru-Hardened Steel M10
Couldn't load pickup availability
SAE J995C Locknut with Nylon Insert Grade 8 5/8-11
Couldn't load pickup availability
Comfort Grip Ergonomic Jumbo Awl, 4 pc Hook & Pick Set
Couldn't load pickup availability
Product Description
• Available in either Type I Automatic Reset or Type III Manual Reset with push-to-trip feature• Rounded profile body and cover boss allow for 3-hole panel cutout mounting
• Standard mounted centers, 8–32 threaded mounting inserts
• Type III Manual Reset type allows opening the circuit path without disconnecting it from the power source
• Voltage rating: 32V DC, for use on 6V, 12V and 24V systems• Ignition protected (ABYC E-9/SAE J1171)
• For either drop-in or rear access mounting
• Applications include marine, RV and agricultural vehicles
Technical Specifications
| Item#: | 50257 |
|---|---|
| Style | Mid-Range Panel-Mounted Circuit Breakers |
| Amperage | 15 A |
| Volts | 32 DC |
| Approvals | Ignition protected (ABYC E-9/SAE J1171) |
| Description | Type III Manual Reset |
| Type | Electrical |
| UNSPSC #: | 39121601 |
| TAA Compliant: | Yes |
| Weight: | 0.11 lb |
