MINI Circuit Breaker, Type II Non Cycling, 10 Amps, Suitable for 12V Systems and Vehicle Circuit Protection
(Pack of
1)
SKU:29846 Item#: 29846
• Smallest circuit breakers available
• Type II, non-cycling, modified reset – remains open as long as power is available or until load is removed
• For 12V electrical systems
• Designed to match the footprint of MINI® Fuses
• Original equipment on Volvo, Mack and Freightliner vehicles
Couldn't load pickup availability
Catalog page#: 19-12
Frequently Bought Together
Type I 15 AMP Circuit Breaker
Couldn't load pickup availability
Universal Plug-In Circuit Breaker Type I 20A
Couldn't load pickup availability
Mid-Range Panel-Mount Circuit Breaker Type I 50A
Couldn't load pickup availability
Cable Tie 7.31" Black
Couldn't load pickup availability
Butt Connector 12 to 10 AWG Clear
Couldn't load pickup availability
Cable Tie 14.19" Black
Couldn't load pickup availability
Environmentally-Sealed Auto Fuse Holder 32V 3-30A
Couldn't load pickup availability
MINI Fuse 2A Gray
Couldn't load pickup availability
MINI Fuse 4A Pink
Couldn't load pickup availability
USS Flat Washer Thru-Hardened Steel 1/4"
Couldn't load pickup availability
Flat Washer Grade 12 Thru-Hardened Steel M8
Couldn't load pickup availability
IFI 100/107 Top Locknut Grade C 5/8-11
Couldn't load pickup availability
Product Description
• Smallest circuit breakers available• Type II, non-cycling, modified reset – remains open as long as power is available or until load is removed
• For 12V electrical systems
• Designed to match the footprint of MINI® Fuses
• Original equipment on Volvo, Mack and Freightliner vehicles
Technical Specifications
| Item#: | 29846 |
|---|---|
| Style | Mini Circuit Breakers |
| Amperage | 10 A |
| Volts | 14 DC |
| Type | Vehicle Circuit Protection |
| UNSPSC #: | 39121601 |
| TAA Compliant: | Yes |
| Weight: | 0.01 lb |
