Ring Tongue Terminal 16 to 14 AWG Blue
(Pack of
25.0)
The dual protection of heat shrink tubing, pre-shrunk around a nylon-insulated terminal, is an excellent product for harsh, over-the-road and off-road heavy equipment applications.
• Dual wall self-seals if accidentally punctured prior to heating
• Clear tubing allows visual inspection and shrinks faster than standard tubing
• Inspection hole completely seals when heat is applied
• Provides positive strain relief at the flex point
• Vapor-proof bond protects connection from moisture, air, dirt, dust, oil and abrasion
3-Piece Heat Seal
• Tensile strength: 2,200 PSI• Elongation: 600%• Rated at 600V
Couldn't load pickup availability
California Proposition 65: Not Applicable
www.P65Warnings.ca.gov
Catalog Page#: 17-13
Frequently Bought Together
DT Series Plug 13A 2 Contacts
Couldn't load pickup availability
Socket Contact 20-16 AWG Size 16
Couldn't load pickup availability
Pin Contact 14 AWG Size 16
Couldn't load pickup availability
Ring Tongue Terminal 16 to 14 AWG Clear 3/8" Stud
Couldn't load pickup availability
Ring Tongue Terminal 8 AWG
Couldn't load pickup availability
Ring Tongue Terminal 12 to 10 AWG Yellow
Couldn't load pickup availability
Hex Nut Grade 8 Alloy Steel 5/8-11
Couldn't load pickup availability
PTO Pin Lock 1/4 x 2-1/2"
Couldn't load pickup availability
Flat Washer Grade 12 Thru-Hardened Steel M8
Couldn't load pickup availability
Female Disconnect Terminal 16 to 14 AWG Blue
Couldn't load pickup availability
Male Quick Slide Terminal 16 to 14 AWG Blue
Couldn't load pickup availability
Female Quick Slide Terminal 12 to 10 AWG Yellow
Couldn't load pickup availability
Product Description
The dual protection of heat shrink tubing, pre-shrunk around a nylon-insulated terminal, is an excellent product for harsh, over-the-road and off-road heavy equipment applications.• Dual wall self-seals if accidentally punctured prior to heating
• Clear tubing allows visual inspection and shrinks faster than standard tubing
• Inspection hole completely seals when heat is applied
• Provides positive strain relief at the flex point
• Vapor-proof bond protects connection from moisture, air, dirt, dust, oil and abrasion
3-Piece Heat Seal
• Tensile strength: 2,200 PSI• Elongation: 600%• Rated at 600V
Technical Specifications
| Item#: | 90875 |
|---|---|
| Type | Crimp and Heat Shrink |
| Wire Gauge | 16-14 AWG |
| Stud Size | 5/16 " |
| Color | Blue |
| UNSPSC #: | 39121432 |
| TAA Compliant: | Yes |
| Weight: | 0.12 lb |
