Sling, Wire, Mesh, Triangle/Choker, Type 1, 3" x 8', 10 Gauge Heavy Duty, V-3500 lb, C-3500 lb, B-7000 lb
(Pack of
1)
SKU:1417091 Item#: 1417091
Made with high tensile steel mesh and alloy steel end fittings, these slings are widely used in metalworking shops and steel warehouses where loads are abrasive, hot or tend to cut web slings.
• Great for use in metalworking shops
• Steel construction resists abrasion and cutting
• Good flexibility and low stretch reduce load damage
• Mesh width helps control and balance loads
• Each sling proof tested and certified
The choker fitting must not be positioned against a load edge or directly on the triangle fitting.
Non-Stock items are made-to-order and are non-returnable.
Do not exceed rated capacities. Sling capacity decreases as the angle from horizontal decreases. Slings should not be used at angles of less than 30°.
Frequently Bought Together
Screw Pin Anchor Shackle, 1/2", 6,000 lb WLL
Couldn't load pickup availability
Tarp Strap Epdm Rubber with Hooks 24" Long
Couldn't load pickup availability
Screw Pin Anchor Shackle, 5/8", 9,000 lb WLL
Couldn't load pickup availability
Cross-Over Socket Extension Set, 3/8" Drive, 3 Piece
Couldn't load pickup availability
Butt Connector 22 to 18 AWG Red
Couldn't load pickup availability
SAE J995C Locknut with Nylon Insert Grade 8 1/4-20
Couldn't load pickup availability
Permaloc™ Wire Rope Sling, Sliding Choker, Steel, 6' Length
Couldn't load pickup availability
Webmaster® 1600 Web Sling, Nylon, Yellow, 6' Length
Couldn't load pickup availability
Webmaster® 1600 Web Sling, Polyester, Yellow, 6' Length
Couldn't load pickup availability
Roughneck™ Wire Mesh Sling, 6' Length
Couldn't load pickup availability
Product Description
Made with high tensile steel mesh and alloy steel end fittings, these slings are widely used in metalworking shops and steel warehouses where loads are abrasive, hot or tend to cut web slings.• Great for use in metalworking shops
• Steel construction resists abrasion and cutting
• Good flexibility and low stretch reduce load damage
• Mesh width helps control and balance loads
• Each sling proof tested and certified
The choker fitting must not be positioned against a load edge or directly on the triangle fitting.
Non-Stock items are made-to-order and are non-returnable.
Do not exceed rated capacities. Sling capacity decreases as the angle from horizontal decreases. Slings should not be used at angles of less than 30°.
Technical Specifications
| Item#: | 1417091 |
|---|---|
| Manufacturer Model #: | 3T110X8 |
| Style | Triangle/Choker |
| Type | Type 1 |
| Material | Steel (10 Gauge) |
| Length | 8 ft |
| Width | 3 " |
| Rated Capacity: Vertical | 3,500 lb |
| Rated Capacity: Choker | 3,500 lb |
| Rated Capacity: Basket | 7,000 lb |
| Maximum Temperature | 550 °F |
| UNSPSC #: | 24101611 |
| TAA Compliant: | Yes |
