SPR; Overall Len: 10mm; Dia: 5.3mm; Inside Dia: 3.15mm; Head Dia: 7.8mm; Head Style: Hollow; Hinge Pillar
(Pack of
10)
Self-piercing rivets (SPR) join two or more pieces of material using a rivet without a pre-drilled hole. Self-piercing rivets are a semi-tubular rivet driven at high force through the material layers to be joined, into a die which causes the tail of the rivet to flare out and form a joint. The process requires no hole preparation and delivers high static strength similar to, or better than, spot welding. This process produces a fatigue resistant joint that is stronger than spot welding and less susceptible to corrosion. The use of coated, lightweight and high-strength materials, such as galvanized or pre-painted steel and aluminum makes welding these materials difficult and often not possible.
Specs are approximate and for identification only. Refer to Ford Service Kit instructions as to the proper SPR for your application.
Couldn't load pickup availability
California Proposition 65: Not Applicable
www.P65Warnings.ca.gov
Frequently Bought Together
PZ Series Zinc Clip-On Wheel Weight 1-1/4oz
Couldn't load pickup availability
PZ Series Zinc Clip-On Wheel Weight 3/4oz
Couldn't load pickup availability
Steel Wiring Harness Clip Large
Couldn't load pickup availability
Radiator Panel Retainer Nylon 1"
Couldn't load pickup availability
Slotted Hex Washer Head License Plate Screw Steel
Couldn't load pickup availability
Symphony All Season Blade 22"
Couldn't load pickup availability
Shroud Insulating Button Nylon 11/16"
Couldn't load pickup availability
Bumper Cover and Fender Shield Push-Type Retainer
Couldn't load pickup availability
PZ Series Zinc Clip-On Wheel Weight 2oz
Couldn't load pickup availability
IFI 100/107 Top Locknut Grade C 5/8-11
Couldn't load pickup availability
SAE Flat Washer Thru-Hardened Steel 1/4"
Couldn't load pickup availability
Hex Nut Grade 8 Alloy Steel 3/8-16
Couldn't load pickup availability
Closed End Rivet 3/16 Diameter. 1/4-3/8 Grip
Couldn't load pickup availability
Window Regulator Roller and Rivet Kit
Couldn't load pickup availability
Specialty Rivet 1/8 Diameter 3/16-1/4 Grip Al
Couldn't load pickup availability
Product Description
Self-piercing rivets (SPR) join two or more pieces of material using a rivet without a pre-drilled hole. Self-piercing rivets are a semi-tubular rivet driven at high force through the material layers to be joined, into a die which causes the tail of the rivet to flare out and form a joint. The process requires no hole preparation and delivers high static strength similar to, or better than, spot welding. This process produces a fatigue resistant joint that is stronger than spot welding and less susceptible to corrosion. The use of coated, lightweight and high-strength materials, such as galvanized or pre-painted steel and aluminum makes welding these materials difficult and often not possible.Specs are approximate and for identification only. Refer to Ford Service Kit instructions as to the proper SPR for your application.
Technical Specifications
| Item#: | 1632569 |
|---|---|
| Code | QC |
| Type | Self-Piercing Rivet |
| Body Diameter | 5.3 mm |
| Make | Ford |
| OEM Number | W717182-S900 |
| Ford OEM Number | W717182-S900 |
| Flange Diameter | 7.8 mm |
| Rivet Length | 10 mm |
| I.D. | 3.15 mm |
| Description | Self-Piercing Rivet |
| Quantity Per Package | 10.0000 |
| F-150 Location | Hinge Pillar |
| Head Style | Hollow |
| UNSPSC #: | 31162200 |
| TAA Compliant: | No |
| Weight: | 0.05 lb |
