Shoulder Eyebolt, Machinery, Self-Colored, M12 x 1.75 x 38
(Pack of 5)

SKU:1442062 Item#: 1442062

Chicago Hardware

Secure, lift, and rig with confidence using our durable machinery eye bolts. Crafted from drop-forged, heat-treated steel, these lifting bolts are designed for industrial-strength performance in workshops, manufacturing plants, and construction sites. Each bolt threads seamlessly into pre-existing tapped holes, providing a reliable anchor point for ropes, cables, or chains during heavy machinery lifts. Built for permanence and safety, our machinery eye bolts are the ultimate solution for industrial rigging and heavy equipment handling.
• Self-colored
• Drop-forged steel
• Heat-treated
CAUTION: Do not exceed working load limits.

Check Availability

Quantity

Catalog page#: 15-19

Frequently Bought Together

Product Description

Technical Specifications

Item#:	1442062
Type	Machinery Eye Bolt
Style	Shoulder Pattern
Material	Forged Steel
Finish	Self-Colored
Thread Size	M12 x 1.75
Shank Length	38.0 mm
Eye I.D.	30 mm
Working Load Limit	1,030 kg
UNSPSC #:	31162600
TAA Compliant:	Yes
Weight:	1.95 lb
