Snap Locking Spade Terminal, Nylon Insulated, 12 to 10 AWG, 1/4" Stud Size, Yellow
(Pack of
50)
SKU:82946 Item#: 82946
Electro-Lok terminals provide a superior solderless crimp terminal connection when compared to other traditional terminal.The butted-seam barrel with a flared seamless brass sleeve provides an extremely strong two-crimp connection.
Electro-Lok terminals feature:
• Full-length crimp barrel for excellent electrical contact
• A second crimp at the flared portion of the sleeve that provides mechanical stress relief and vibration-resistance at the junction of the wire insulation and barrel
• Molded see-through nylon insulation that provides high-quality, tough, chemical-resistant electrical insulation for industrial applications
Electro-Lok
• Won’t drop off the stud when the nut loosens• Spring-like tongue locks in place around the stud even when mount screw is not tightened• Extra force is required to remove from stud• Manufactured from high-grade copper for the highest conductivity• Annealed to flow freely under crimping pressure for best connection• Electro-tin-plated for greatest corrosion resistance• 600V
Couldn't load pickup availability
Catalog page#: 17-20
Frequently Bought Together
Ring Tongue Terminal 16 to 14 AWG Blue
Couldn't load pickup availability
Hex Nut Grade 5 Steel 3/8-16
Couldn't load pickup availability
Block Spade Terminal 12 to 10 AWG Yellow
Couldn't load pickup availability
Ring Tongue Terminal 16 to 14 AWG Blue
Couldn't load pickup availability
Product Description
Electro-Lok terminals provide a superior solderless crimp terminal connection when compared to other traditional terminal.The butted-seam barrel with a flared seamless brass sleeve provides an extremely strong two-crimp connection.Electro-Lok terminals feature:
• Full-length crimp barrel for excellent electrical contact
• A second crimp at the flared portion of the sleeve that provides mechanical stress relief and vibration-resistance at the junction of the wire insulation and barrel
• Molded see-through nylon insulation that provides high-quality, tough, chemical-resistant electrical insulation for industrial applications
Electro-Lok
• Won’t drop off the stud when the nut loosens• Spring-like tongue locks in place around the stud even when mount screw is not tightened• Extra force is required to remove from stud• Manufactured from high-grade copper for the highest conductivity• Annealed to flow freely under crimping pressure for best connection• Electro-tin-plated for greatest corrosion resistance• 600V
Technical Specifications
| Item#: | 82946 |
|---|---|
| Type | Crimp |
| Style | Nylon Insulated |
| Wire Gauge | 12-10 AWG |
| Stud Size | 1/4 " |
| Color | Yellow |
| UNSPSC #: | 39121432 |
| TAA Compliant: | No |
| Weight: | 0.17 lb |
