Step-Down Butt Connector 16 to 14/22 to 18 AWG Red
(Pack of
10)
• Seal and protect electrical connections against failure due to water, moisture, corrosion, vibration and strain
• Dual wall heat shrink tubing pre-shrunk around an electro-tin-plated copper butt splice
• The inner wall adhesive hot-melts into the wire insulation to encapsulate and seal the connection
• Outer wall shrinks to provide strength with flexibility
• Unaffected by most oils, fuels, solvents, chemicals and road salts
• Color-coded, semi-transparent insulation for excellent crimping every time
• Self-seals if accidentally punctured prior to heating
• Tensile strength: 3,200 PSI minimum• Elongation: 200% minimum• Working voltage: 600V• Continuous operating temperature: –67°F to +230°F (–55°C to +110°C)• Minimum shrink temperature: 248°F (120°C)
• Butt connectors have a unique, double-thick insulation for burial, water-exposed, high-stress and vibration applications
Couldn't load pickup availability
California Proposition 65: Not Applicable
www.P65Warnings.ca.gov
Frequently Bought Together
Step-Down Butt Connector 12 to 10/16 to 14 AWG
Couldn't load pickup availability
Butt Connector 16 to 14 AWG Blue
Couldn't load pickup availability
Butt Connector 16 to 14 AWG Blue
Couldn't load pickup availability
Right Angle Safety LED Light 3x AA 7.44"
Couldn't load pickup availability
Cable Tie 13.38" Black
Couldn't load pickup availability
Tru-Shrink Heat Shrink Tubing 8 to 1 AWG Black
Couldn't load pickup availability
SAE J995C Locknut with Nylon Insert Grade 8 1/4-20
Couldn't load pickup availability
SAE Flat Washer Thru-Hardened Steel 3/8"
Couldn't load pickup availability
Flat Washer Grade 12 Thru-Hardened Steel M8
Couldn't load pickup availability
Butt Connector 22 to 18 AWG Red
Couldn't load pickup availability
Ring Tongue Terminal 16 to 14 AWG Clear #10 Stud
Couldn't load pickup availability
Ring Tongue Terminal 16 to 14 AWG Blue
Couldn't load pickup availability
Product Description
• Seal and protect electrical connections against failure due to water, moisture, corrosion, vibration and strain• Dual wall heat shrink tubing pre-shrunk around an electro-tin-plated copper butt splice
• The inner wall adhesive hot-melts into the wire insulation to encapsulate and seal the connection
• Outer wall shrinks to provide strength with flexibility
• Unaffected by most oils, fuels, solvents, chemicals and road salts
• Color-coded, semi-transparent insulation for excellent crimping every time
• Self-seals if accidentally punctured prior to heating
• Tensile strength: 3,200 PSI minimum• Elongation: 200% minimum• Working voltage: 600V• Continuous operating temperature: –67°F to +230°F (–55°C to +110°C)• Minimum shrink temperature: 248°F (120°C)
• Butt connectors have a unique, double-thick insulation for burial, water-exposed, high-stress and vibration applications
Technical Specifications
| Item#: | KT13697 |
|---|---|
| Type | Crimp and Heat Shrink |
| Wire Gauge | 16-14 to 22-18 AWG |
| Color | Blue |
| Length | 1.50 " |
| Full Barrel End | 16-14 AWG |
| Step-Down Barrel End | 22-18 AWG |
| Full Barrel End Accommodates | One 14 Ga., One 16 Ga., One 16 and One 18 Ga., or Two 18 Ga. Wires |
| Step-Down Barrel End Accommodates | One 18 Ga., One 22 Ga., or Two 22 Ga. Wires |
| Maximum Splice Length | 0.695 " |
| Voltage Rating | 600 V |
| Operating Temperature Range | -67 to 230 °F |
| Shrink Temperature | 248 F |
| Elongation | 200 % |
| Maximum Wire Insulation | 0.190 " |
| Style | Heat Seal Step-Down Butt Connectors |
| UNSPSC #: | 39121409 |
| TAA Compliant: | Yes |
| Weight: | 0.07 lb |
