Temflex™ 165 Vinyl Electrical Tape, Black, 3/4" Width, 60' Length, 200% Elongation, 32 to 176°F Temperature Rating
(Pack of
10)
SKU:P34103 Item#: P34103
• Exclusive PVC memory provides smooth, tight taping jobs
• Prevents loose wires and connections
• Resists oil, gas, water, grease and acid
• Each roll individually wrapped
• Specially developed for automotive and truck electrical taping and repairs
Frequently Bought Together
Socket Contact 20-16 AWG Size 16
Item#: 29488
Couldn't load pickup availability
Super 33+ Series Vinyl Electrical Tape Black 3/4"
Item#: 54518
Couldn't load pickup availability
Tru-Shrink Heat Shrink Tubing 14 to 6 AWG Black
Item#: 86502
Couldn't load pickup availability
Hex Nut Grade 8 Alloy Steel 1/2-13
Item#: A104
Couldn't load pickup availability
Self-Drilling Screw Hex Head #10-16 x 3/4"
Item#: 84931
Couldn't load pickup availability
SAE J995C Locknut with Nylon Insert Grade 8 5/8-11
Item#: 53985
Couldn't load pickup availability
Vinyl Electrical Tape Red 3/4" x 66'
Item#: 1145933
Couldn't load pickup availability
Posi-Seal Plus Patch Black 2-1/2 x 2-1/2" Pads
Item#: KT13080
Couldn't load pickup availability
Seal Tite Fusion Wrap Gray 1"
Item#: P29950
Couldn't load pickup availability
Vinyl Electrical Tape Red 3/4" x 66'
Item#: 90232
Couldn't load pickup availability
Heat Shrink Tubing 16 to 14 AWG Blue
Item#: 56855
Couldn't load pickup availability
Tru-Shrink Heat Shrink Tubing 8 to 4 AWG Black
Item#: 61660
Couldn't load pickup availability
Product Description
• Exclusive PVC memory provides smooth, tight taping jobs• Prevents loose wires and connections
• Resists oil, gas, water, grease and acid
• Each roll individually wrapped
• Specially developed for automotive and truck electrical taping and repairs
Technical Specifications
| Item#: | P34103 |
|---|---|
| Manufacturer Model #: | 1700 |
| Type | Individual Roll |
| Style | PVC Electrical Tape |
| Color | Black |
| Dielectric Strength | 1000 V/mil |
| Length | 60 ft |
| Width | 3/4 " |
| Thickness | 7 mil |
| Temperature Range | 32 to 176 °F |
| Celcius Temperature Range | 0 to 80 °C |
| Elongation | 200 % |
| Adhesion to Steel | 22 in. oz. |
| Adhesion to Backing | 22 in. oz. |
| Adhesive Material | Rubber Resin |
| Backing Material | Polyvinyl Chloride |
| Breaking Strength | 17 lb./in. |
| Voltage Rating | 600 V |
| Approvals | ASTM, CSA, MSHA, UL |
| Description | 3/4" x 60' Roll |
| UNSPSC #: | 31201502 |
| TAA Compliant: | Yes |
| Weight: | 1.72 lb |
