Wire Thread Insert Repair Kit, 7 Pieces, 1-8, 304 Stainless Steel, 200000PSI Tensile Strength
(Pack of 1)

SKU:53832 Item#: 53832

Fix-A-Thred®

• Helically-wound thread repair – universally accepted and most cost-effective method of thread repair
• Manufactured from precision cold-formed 18-8 (Type 304) stainless steel
• Kits contain tap, inserts, installation tool, tang removal tool (select kits) and instructions, packaged in a sturdy and convenient storage box
• Inserts compensate for pitch and angle errors and share the load over more of the thread for stronger assemblies
• Tensile strength of at least 200,000 PSI
• Wide effective temperature range: –275°F to +774°F (–170°C to +412°C)
Fix-A-Thred® Insert Installation InstructionsDrill to clear out the damaged thread (if necessary).Thread insert tap supplied. Tap thread should match up with bolt.Wind insert in with light downward pressure until 1/4 to 1/2 turn below surface, driving tang towards bottom of the hole.Remove tool and sit back on top of tang. Tap down sharply. Do not try to twist tang off. For large fine threads, use long nose pliers and pull tang out.
To insure proper installation of inserts, always use the correct and corresponding tools.
CAUTION: Any cutting tool may break or shatter under improper use. Government regulations require use of safety glasses and other appropriate safety equipment at all times in the vicinity of use.

Check Availability

Quantity

California Proposition 65: WARNING: Cancer and Reproductive Harm -
www.P65Warnings.ca.gov

Catalog page#: 11-64

Frequently Bought Together

Jobber Length Drill Bit HSS 7/64"

Scotch-Brite Roloc Surface Conditioning Disc 2"

Abrasive Hand Pad All Purpose 6 x 9"

SAE Flat Washer Thru-Hardened Steel 3/8"

Lawson Open & Shut Nut & Bolt Loosener, Rust Penetrant, SKU DA6152, 20 oz Aerosol Can

SAE J995C Locknut with Nylon Insert Grade 8 1/4-20

Spiral Fluted Screw Extractor 5/16 to 7/16"

Thin Wall Locking Thread Insert Kit M8 x 1.25

Wire Thread Replacement Insert 7/16-14

Index-Tend Demo Wrecking Bar

Item#: DY89320027

21-Piece, 1/4" Shank, 2" Hex Power Bit Set

Twist-On Surface Conditioning Disc 2" Brown

Wire Thread Insert Repair Kit M20-2.5

Wire Thread Insert Repair Kit M14-2

Wire Thread Insert Repair Kit M16-1.5

Product Description

• Helically-wound thread repair – universally accepted and most cost-effective method of thread repair
• Manufactured from precision cold-formed 18-8 (Type 304) stainless steel
• Kits contain tap, inserts, installation tool, tang removal tool (select kits) and instructions, packaged in a sturdy and convenient storage box
• Inserts compensate for pitch and angle errors and share the load over more of the thread for stronger assemblies
• Tensile strength of at least 200,000 PSI
• Wide effective temperature range: –275°F to +774°F (–170°C to +412°C)
Fix-A-Thred® Insert Installation InstructionsDrill to clear out the damaged thread (if necessary).Thread insert tap supplied. Tap thread should match up with bolt.Wind insert in with light downward pressure until 1/4 to 1/2 turn below surface, driving tang towards bottom of the hole.Remove tool and sit back on top of tang. Tap down sharply. Do not try to twist tang off. For large fine threads, use long nose pliers and pull tang out.
To insure proper installation of inserts, always use the correct and corresponding tools.
CAUTION: Any cutting tool may break or shatter under improper use. Government regulations require use of safety glasses and other appropriate safety equipment at all times in the vicinity of use.

Item#:	Description	QTY:
53789	Fix-A-Thred® Wire Thread Insert, 1-8	5
61340	Fix-A-Thred® Hand Tap, 1-8	1
53771	Fix-A-Thred® Installation Tool	1

Technical Specifications

Item#:	53832
Type	Insert Repair Kit
Size	1-8
Recommended Drill Size	1-1/32 "
Number of Pieces	7
UNSPSC #:	27112810
TAA Compliant:	Yes
Weight:	3.66 lb
