100 Blue Lightning Tough Duplex Alloy 3/32
(Pack of
5.0)
A tough duplex alloy designed for dissimilar welding applications of ferrous metals (except cast iron).
• AC Welding – Special flux coating enhances operability on buzz boxes and DC inverter welders
• High Strength – Resistant to heat and corrosion, but still machinable
• High Elongation – Tough welds stand up to impact and shock
• Versatile – Welds steel, stainless steel, manganese steel, HY steels, alloy steels, tool steels and nickel alloys to steel and dissimilar combinations of these alloys
• All-position welding and easy slag removal
• Tensile strength: – As deposited: 95,000 PSI/655 MPa – Work Hardened: Up to 130,000 PSI/896 MPa
• Hardness: – As Deposited: 93 Rb – Work hardened: Up to 35 Rc
• Elongation: 30%
• Machinability: Excellent
• Heat Resistance: Good
• Corrosion Resistance: Good
• Current: DCEP (DC+) or AC
Frequently Bought Together
333 Dissimilar Steel Stick Rod Electrode 5/32"
Couldn't load pickup availability
333 Dissimilar Steel TIG Wire 3/32"
Couldn't load pickup availability
333 Dissimilar Steel Stick Rod Electrode 1/16"
Couldn't load pickup availability
SAE J995C Locknut with Nylon Insert Grade 8 1/4-20
Couldn't load pickup availability
Stepdown Butt Connector 22 to 18/16 to 14 AWG
Couldn't load pickup availability
Utility Knife, Folding , 4" Closed
Couldn't load pickup availability
ER70S-6 Mild/Carbon Steel MIG Welding Wire 0.035"
Couldn't load pickup availability
163 Arc-Cut Synthetic Carbon Arc Electrode
Couldn't load pickup availability
510 Aluminum TIG Wire 1/16"
Couldn't load pickup availability
657 Premium Bronze Solid Mig Wire .035X30LB SPL
Couldn't load pickup availability
665 Copper and Brass TIG Wire 1/8"
Couldn't load pickup availability
106 Mild Steel All Purpose Electrode
Couldn't load pickup availability
Product Description
A tough duplex alloy designed for dissimilar welding applications of ferrous metals (except cast iron).• AC Welding – Special flux coating enhances operability on buzz boxes and DC inverter welders
• High Strength – Resistant to heat and corrosion, but still machinable
• High Elongation – Tough welds stand up to impact and shock
• Versatile – Welds steel, stainless steel, manganese steel, HY steels, alloy steels, tool steels and nickel alloys to steel and dissimilar combinations of these alloys
• All-position welding and easy slag removal
• Tensile strength: – As deposited: 95,000 PSI/655 MPa – Work Hardened: Up to 130,000 PSI/896 MPa
• Hardness: – As Deposited: 93 Rb – Work hardened: Up to 35 Rc
• Elongation: 30%
• Machinability: Excellent
• Heat Resistance: Good
• Corrosion Resistance: Good
• Current: DCEP (DC+) or AC
Technical Specifications
| Item#: | EG10050000 |
|---|---|
| Welding Process | Stick |
| Type | Electrode |
| Diameter | 3/32 " |
| Tensile Strength | 130,000 PSI |
| Elongation | 30 % |
| Hardness | 35 HRC |
| Polarity | DCEP |
| UNSPSC #: | 23271810 |
| TAA Compliant: | Yes |
| Weight: | 6.09 lb |
