Home Tools Cutting Tools Drill Bits Silver & Deming Drills 37/64" Dia. Fractional Drill Bit with Reduced 1/2" Shank, 118o Point
Cutting Tools
1-3/4
1-3/4

37/64" Dia. Fractional Drill Bit with Reduced 1/2" Shank, 118o Point, W/Flats, 6" Overall Length, Silver & Black
(Pack of 1)

Item#: PM08200359

Lawson Products

• Manufactured from molybdenum high speed tool steel for long life
• 1/2" reduced shank with flats - can be used in keyed or keyless chucks without slipping
• Silver with black-oxide flutes to hold lubricant at the cutting surface
• 118° point for fast cutting
• Available in an eight piece assortment for sizes 9/16" to 1" in. 1/16" increments
Specifications
• Material: Molybdenum high speed steel
• Finish: Silver and black-oxide
• Point: 118° standard
• Overall Length: 6"
• Max. Depth of Cut: 2.1"
• Length of Flats on Shank: 1"
• Shank Diameter: 1/2"
Applications
Steel, aluminum, cast steel, copper, brass, malleable iron, bronze, cast iron
Note: A pilot hole is recommended when using reduced shank bits
CAUTION: Any cutting tool may break or shatter under improper use. Government regulations require use of safety glasses and other appropriate safety equipment at all times in the vicinity of use.

Read More
Check Availability
Usually Ships: Today
While Supplies Last

Frequently Bought Together

Twist-On Surface Conditioning Disc 3

Twist-On Surface Conditioning Disc 3" Maroon

Item#: 17419
Jobber Length Drill Bit HSS 31/64

Jobber Length Drill Bit HSS 9/32"

Item#: 84735
Jobber Length Drill Bit HSS 31/64

Jobber Length Drill Bit HSS 3/8"

Item#: 84741M06
Jobber Length Drill Bit HSS 31/64

Jobber Length Drill Bit HSS 19/64"

Item#: 84736
Mechanic's Length Drill Bit HSS 7/64

Mechanic's Length Drill Bit HSS 1/4"

Item#: 10881M06
1/2

3/8" Fractional Drill Bit, Jobber Length, W/Flats

Item#: PM08200041
USS Flat Washer Thru-Hardened Steel 3/8

USS Flat Washer Thru-Hardened Steel 3/8"

Item#: FA88447
SAE Flat Washer Thru-Hardened Steel 5/16

SAE Flat Washer Thru-Hardened Steel 5/16"

Item#: 88436
Self-Drilling Screw Hex Head #6-20 x 1/2

Self-Drilling Screw Hex Head 1/4-14 x 1"

Item#: 2539
Cryoboost 11/16

Cryoboost 7/8" Reduced Shank, Stepped Split Point

Item#: DY83635664
Cryoboost 11/16

Cryoboost 1" Reduced Shank, Stepped Split Point

Item#: DY83636464
1-3/4

1-1/8"" Dia. Fractional Drill Bit with Reduced 1/2" Shank, 118o Point

Item#: PM08200390
8Pc Metric Mini Double Head Wrench Set, 8Pc, 5mm To 11mm Metric Mini Double Head Wrench Set

8Pc Metric Mini Double Head Wrench Set

Item#: DY89250450
Jobber Length Drill Bit HSS 31/64

Jobber Length Drill Bit HSS 7/32"

Item#: 84731
Jobber Length Drill Bit HSS 31/64

Jobber Length Drill Bit HSS 1/4"

Item#: 84733M06
Nut Torq Tite Hex Flange, #8-32, Nut Torq Tite Hex Flange, Grade 2, Serrated, Coarse, Steel, Zinc Finish, #8-32

Nut Torq Tite Hex Flange, 1/4-20

Item#: DY02551300
USS Flat Washer Steel 5/16

USS Flat Washer Steel 5/16"

Item#: BC502
SAE Flat Washer 3/4

SAE Flat Washer 3/4" 13/16" ID 1-1/2" OD

Item#: P56827
Nut Torq Tite Hex Flange, #8-32, Nut Torq Tite Hex Flange, Grade 2, Serrated, Coarse, Steel, Zinc Finish, #8-32

Nut Torq Tite Hex Flange, 1/4-20

Item#: DY02551300
USS Flat Washer Steel 5/16

USS Flat Washer Steel 5/16"

Item#: BC502
SAE Flat Washer 3/4

SAE Flat Washer 3/4" 13/16" ID 1-1/2" OD

Item#: P56827

Product Description

• Manufactured from molybdenum high speed tool steel for long life
• 1/2" reduced shank with flats - can be used in keyed or keyless chucks without slipping
• Silver with black-oxide flutes to hold lubricant at the cutting surface
• 118° point for fast cutting
• Available in an eight piece assortment for sizes 9/16" to 1" in. 1/16" increments
Specifications
• Material: Molybdenum high speed steel
• Finish: Silver and black-oxide
• Point: 118° standard
• Overall Length: 6"
• Max. Depth of Cut: 2.1"
• Length of Flats on Shank: 1"
• Shank Diameter: 1/2"
Applications
Steel, aluminum, cast steel, copper, brass, malleable iron, bronze, cast iron
Note: A pilot hole is recommended when using reduced shank bits
CAUTION: Any cutting tool may break or shatter under improper use. Government regulations require use of safety glasses and other appropriate safety equipment at all times in the vicinity of use.

Technical Specifications

Item#: PM08200359
Drill Length Silver & Deming
Drill Type Fractional
Type General Purpose
Material High Speed Steel
Finish Silver & Black
Diameter 37/64 "
Decimal Equivalent 0.5781 "
Point 118 °
Shank Size 1/2 "
Flats 3
Overall Length 6 "
UNSPSC #: 23241636
TAA Compliant: No
Weight: 0.31 lb
