Ford OEM Self-Piercing Rivet, 3.5mm Body Diameter, 2.0mm ID, 5.8mm Head Diameter, Solid Head Style, 4.5mm Overall Length
(Pack of
10)
SKU:1637092 Item#: 1637092
Self-piercing rivets (SPR) join two or more pieces of material using a rivet without a pre-drilled hole. Self-piercing rivets are a semi-tubular rivet driven at high force through the material layers to be joined, into a die which causes the tail of the rivet to flare out and form a joint. The process requires no hole preparation and delivers high static strength similar to, or better than, spot welding. This process produces a fatigue resistant joint that is stronger than spot welding and less susceptible to corrosion. The use of coated, lightweight and high-strength materials, such as galvanized or pre-painted steel and aluminum makes welding these materials difficult and often not possible.
Specs are approximate and for identification only. Refer to Ford Service Kit instructions as to the proper SPR for your application.
Frequently Bought Together
PZ Series Zinc Clip-On Wheel Weight 1-1/4oz
Couldn't load pickup availability
PZ Series Zinc Clip-On Wheel Weight 3/4oz
Couldn't load pickup availability
MCN Series Lead Clip-On Wheel Weight 1 oz
Couldn't load pickup availability
Metric Indented Hex Head Bolt with 17mm Washer
Couldn't load pickup availability
Universal Neoprene Captive Brass Well Nut #8-32
Couldn't load pickup availability
Extruded U-Nut Steel M6-1
Couldn't load pickup availability
P Series Lead Clip-On Wheel Weight 0.25oz
Couldn't load pickup availability
Phillips Round Washer Head Trim Drill Point Screw
Couldn't load pickup availability
Front and Rear Bumper Fascia Retainer Plastic 1"
Couldn't load pickup availability
Hex Nut Grade 8 Alloy Steel 3/8-16
Couldn't load pickup availability
PTO Pin Lock 1/4 x 2-1/2"
Couldn't load pickup availability
Hex Nut Grade 8 Alloy Steel 1/2-13
Couldn't load pickup availability
Specialty Rivet 1/8 Diameter 1/8-3/16 Grip Al
Couldn't load pickup availability
Rivet 1/8 Diameter. 1/16-1/8 Grip 1/4 Flange
Couldn't load pickup availability
Upper Vent Pivot Tubular Rivet
Couldn't load pickup availability
Product Description
Self-piercing rivets (SPR) join two or more pieces of material using a rivet without a pre-drilled hole. Self-piercing rivets are a semi-tubular rivet driven at high force through the material layers to be joined, into a die which causes the tail of the rivet to flare out and form a joint. The process requires no hole preparation and delivers high static strength similar to, or better than, spot welding. This process produces a fatigue resistant joint that is stronger than spot welding and less susceptible to corrosion. The use of coated, lightweight and high-strength materials, such as galvanized or pre-painted steel and aluminum makes welding these materials difficult and often not possible.Specs are approximate and for identification only. Refer to Ford Service Kit instructions as to the proper SPR for your application.
Technical Specifications
| Item#: | 1637092 |
|---|---|
| Type | Self-Piercing Rivet |
| Body Diameter | 3.5 mm |
| Diameter | 3.5 mm |
| Length | 4.5 mm |
| Make | Ford |
| OEM Number | W718595-S900 |
| Ford OEM Number | W718595-S900 |
| Flange Diameter | 5.8 mm |
| Material | Steel |
| Rivet Length | 4.5 mm |
| I.D. | 2.0 mm |
| Description | Self-Piercing Rivet |
| Quantity Per Package | 10.0000 |
| Head Diameter | 5.8 mm |
| Head Style | Solid |
| UNSPSC #: | 25172502 |
| TAA Compliant: | Yes |
| Weight: | 0.05 lb |
